Table 12: VSP 7432CQ Front Panel System LEDs (continued)
Label or Type
PWR
(Power)
Table 13: VSP 7400-48Y Front Panel System LEDs
Label or Type
PSU1,PSU2
(Power Supplies)
FAN
SYS
(System)
PWR
(Power)
Table 14: VSP 7400-48Y Front Panel 100/1G RJ45 Port LEDs
Label or Type
OOB Management Port
(Link/Activity)
OOB Management Port
(Speed)
VSP 7400 Series Switches: Hardware Installation Guide
Color/State
Steady green
Blinking green
Off
Color/State
Steady green
Steady amber
Off
Steady green
Steady amber
Off
Steady green
Blinking green
Steady amber
Blinking amber
Off
Steady green
Blinking green
Off
Color/State
Steady green
Blinking green
Off
Blinking green
Steady green
Off
Monitoring the Switch
Meaning
Normal operation
System in reset
Unit not operational
Meaning
PSU is installed and providing power
PSU is installed but input power is disconnected or
unit fault detected
PSU is not installed
All fans operating normally
A fan has been removed or fault detected
No power to fan modules
Normal operation; agent software code has been
loaded
Loading the agent software code
Error encountered while running diagnostic
software
Loading and executing the boot loader or
diagnostic software
Unit not operational
Normal operation
System in reset
Unit not operational
Meaning
Network link
Network link and activity
Link at 10Mbps or no activity
Port link at 100Mbps
Port link at 1000Mbps
Link at 10Mbps or no link
