Display
Timers
Timer 1
Timer 2
Timer 3
Timer 4
Timer 5
Timer 6
Activate/Deactivate
Disable calls
Stop calls
I/O Line
Generic alarm
Generic fault
Activate/Deactivate
Extinction
Disable extinguishing
Disable Automatic Extinc.
Stop valve pulse
Section for the management of the timers
Status
programmed for the selected control panel.
Stand-by
The activation status of each timer is shown
Stand-by
and made distinctive by colour:
Active
• Green, timer deactivated
Active
• Red, timer activated
Stand-by
• Blue, selected timer
Stand-by
By selecting a timer and pressing the Activate/
Deactivate button, it will be possible to
Esc
change its activation status. The Disable
button allows you to change the operating
mode.
Section
communicator and access to the telephone
functions of the selected control panel.
In the section on the left, when necessary, the
ongoing fault is described.
The section on the right contains the following
buttons:
• Disable calls, for the disablement of calls
Esc
• Stop calls, for the interruption of ongoing
calls
Section for viewing the devices connected to
Status
the terminals of the selected control panel.
Stand-by
The status of each line is shown and made
Fault
distinctive by colour:
• Green, line in standby
• Yellow, line in fault status or bypassed
• Red, line in alarm status
• Blue, selected line
By selecting a line and pressing the Activate/
Esc
Deactivate button, it will be possible to
change the activation status. The Disable
button allows you to change the operating
mode.
Section for the management of the extinction
channel of the selected control panel (where
available).
The section on the left shows the information
relative to the extinction channel.
The section on the right contains the buttons
for the management of the channel:
• Disable extinguishing
• Disable automatic extinguishing
Esc
• Stop valve pulse
Fire detection and extinguishant system
Section
for the management
Viewing the system
of the
