Function LEDs
Signalling
test
Evacuate
Investigate
Silence
buzzer
Silence
sounder
Reset
Multiple
alarms
3.3

Screen in standby status

Buttons to access the events
[A]
logs, system status and
programming.
Status bar (always present)
[B]
shows essential information
regarding the system.
Customizable area
(customizable during the
programming phase) for images
[C]
relating to the status of the
system elements or customized
function buttons .
Date and Time of the system
Selection of the indication
[D]
accesses (at level 2) the date
and time setting window
Button to change the language
[E]
used by the control panel, if
required by the configuration
User interface
Colour On solid
The test on the visual
Yellow
signalling devices is running.
The evacuation phase has
Red
been activated manually.
The investigation time has
Yellow
been activated.
The buzzer has been
Yellow
silenced.
The sounders have been
Yellow
silenced.
The reset function is
disabled. The sounders
Yellow must be silenced before the
Reset function can be re-
enabled.
More than one alarm is
Red
active on the system.
B
L:1
Function button
If this button is pressed and held all the LEDs
on the control panel will light.
Button for manual activation of the signalling
devices (audible and visual) for evacuation of
Button to request supplementary investigation
time and thus lengthen the early-warning
This button silences the control panel buzzer.
Events which occur after silencing will
reactivate the buzzer.
During alarm status, this button can be used
to stop the audible and visual signalling
Pressing this button again will reactivate the
silenced audible and visual signalling devices.
Button for the annulment of active events and
the reset of standby conditions.
This button allows you to scroll through the
active alarm events on the screen.
C
D
E
the premises.
period.
devices.
Log
A
System status
Programming
