3.4

Status Bar

Icon
Access level:1
Language
selection
Day/Night
status
Mains
network
Alarm
signaller status
12
Selection of this area allows you to enter a code and change the current user-access
- 1 = Public level (no code entry)
- 2 = Supervision level (turn key or user code entry)
- 3 = Programming level (installer code entry)
If required by the configuration, this button will appear on the status bar.
Selection of one of the icons will change the language used by the control panel.
Selection of this icon (at level 2) allows you to switch from day mode to night mode or vice
- The control panel runs the early warning phase before activating an alarm
triggered by a detector
- the sensitivity of the detectors is set in day mode
- early warnings are not run
- the sensitivity of the detectors is set in night mode
- in the event of an alarm, if the sounders are silenced they will reactivate
automatically after a set time.
Selection of this icon displays a screen showing the voltages, currents and temperatures of the
Selection of this icon accesses (at level 2) a menu which allows manual deactivation, activation
and silencing of all fire alarm signalling devices.
Fire-alarm signalling devices (sounders, etc.) are in standby status and are operating
At least one fire alarm signalling device is in fault status. Contact your service dealer.
At least one fire alarm signalling device has been activated
Function
level.
versa.
Day Mode:
Night Mode:
power section.
Mains power-supply functioning properly
Indicates mains-power failure
properly.
At least one fire alarm signalling device is disabled.
Fire detection and extinguishant system
User interface
