Viewing the system
5.1

Viewing active events

If there are any active events, that is, at least one condition worthy of note has been detected in the system and is
currently active, the display stand-by screen (paragraph 3.3) will be replaced by a screen which provides the respective
notification.
The screen will show the active events on the system
grouped in categories.
represented by the icons at the top [A] which are enabled
when events occur and show below the number of events
of the currently active type [B].
Touching any one of these buttons allows you to view all
the events in the associated category. The events are listed
in a chronological order [C] and can be scrolled with the
arrow keys.
By selecting with a touch an event generated by a loop
device, you will access the management page of the device
itself (refer to paragraph 6.2 Device management).
Icons for categories for which there are currently no active events do not appear.
After 30 seconds of inactivity the screen will automatically go to the screen containing the category of events with the
highest priority. The priority is shown in the following list:
Priority Icon
1
2
3 Early warning
4
5
6
7 Disablements
16
The various categories
These indicate potentially dangerous conditions which require maximum attention.
Fire alarm
When an alarm occurs, the section below the event buttons [B] shows the pre-alarm
time count in progress and then, alarm over, the summary of information on the
Gas alarm
These indicate potentially dangerous conditions which require maximum attention.
Signalling triggered by detectors with a threshold below that set for alarms.
Cautionary alert which must be evaluated with attention and verified.
Signalling of the activation of a device that has a control function (supervision) of
Supervision
Indicates a risk which may jeopardize the proper operating capacity of the system.
They represent risk conditions that may compromise the proper operating capacity of
Fault
These are non-alarm or fault signals that can be configured during installation,
Monitor
They are signals of minor importance and the level of attention required depends on
the use made of these signals during the system configuration phase.
These signals indicate the disablement of one or more of the system elements.
They Indicate that it is necessary to consider that parts of the system might not be
are
Alarms 1/2
B
01/01/2020 18:23 - EVACUATION
PREVIDIA COMPACT
Access level:1
Category
Signalling associated with fire-alarm conditions.
zones in alarm.
Signalling associated with gas-detection alarm conditions.
another part of the system.
Verify the signalled condition carefully.
Signals relating to of faults detected in the system.
the system.
Contact your service dealer.
normally used to provide indications to the user.
operative.
Fire detection and extinguishant system
Chapter 5
A
C
Viewing the system
