Specifications
LCD Panel
Display Type
Max. Resolution
Brightness
Color
Pixel Pitch (H x V)
Viewing Angle
Contrast
Backlight Lifetime
Touchscreen Type
Light Transmission
Controller
Durability
Processor
Memory
Storage
Network (LAN)
I/O
Expansion
Speaker
OS Support
Power Supply
Power Consumption*
Operating Temperature
Storage Temperature
Relative Humidity
Shock
Vibration
Safety and EMC
Dimensions
Weight
*Power consumption test conditions:
Windows 10 (64 bit), Burn-In 8.0, COM port RS-232, 4 x loopbacks, 3 x USB 3.0 devices, and 1 x USB mouse
2 PPC-3100/3120 Startup Manual
PPC-3100-RE9A
10.4"
TFT LCD
800 x 600
400 nits
262k/16.2M
0.264 x 0.264
160°, 140°
700
30,000 hrs (minimum)
5-wire resistive touch
80±5%
USB interface
At least 35 million touches at the same point without failure
Intel® Atom™ E3940 quad core
1 x SODIMM DDR3L 1866 MHz (max. 8 GB)
1 x 2.5" SATA bay, 1 x mSATA bay
2 x 10/100/1000 Mbps Ethernet
5 x Serial ports: 4 x RS-232, 1 x isolated RS-422/485 (adjustable via BIOS)
4 x USB 3.0
1 x Line-out, 1 x Mic-in
1 x VGA
1 x HDMI
1 x GPIO (8 channels, TTL level, internal)
1 x Mini PCIe
Optional for PPC-3120: 1 x PCIe x1 or 1 x PCI
2 x 1W
Microsoft
Windows 10 (64 bit), Windows 10 LTSC, Linux, Android 8.1
®
9 ~ 32 V
DC
25W
0 ~ 50 °C (32 ~ 122 °F) with 2.5" SATA SSD
-20 ~ 60 °C (-4 ~ 140 °F) with -40 ~ 85 °C mSATA or 2.5" SATA SSD
-30~ 60 °C (-22 ~ 140 °F)
10 ~ 95% @ 40 °C (non-condensing)
Operating 10G peak acceleration (11 ms duration), in accordance with IEC 60068-2-27
Operating random vibration test, 5 ~ 500 Hz, 1Grms with HDD/ 2Grms with SSD,
in accordance with IEC 60068-2-64
Safety: CB, UL, CCC
EMC: CE, FCC Class B, BSMI
271.8 x 216.8 x 57.5 mm (10.7 x 8.5 x 2.3 in)
2.8 kg (6.17 lb)
PPC-3120-RE9A
12.1"
TFT LCD
1024 x 768
600 nits
262k/16.2M
0.240 x 0.240
160°, 140°
700
50,000 hrs (minimum)
36W
-40 ~ 60 °C (-40 ~ 140 °F)
317 x 246 x 60.5 mm (12.5 x 9.7 x 2.4 in)
3.4 kg (7.5 lb)
