Setting:
Languages:
In the "Languages" menu option, you can select the desired language� A check mark (√)
indicates the language that is set for the system�
Units:
In the "Units" menu option, you can select the desired unit (°C or °F) for the temperature� A
check mark (√) indicates the unit that is set for the system�
Display:
In the "Background" menu option you select black or white color for the working screen�
In the "Firmware Update Information" menu option, you can activate or deactivate the
"Firmware Update Information" screen at the starting of the device� A check mark (√)
indicates that the menu option is activated�
Sound:
In the "Sound" menu option, you can activate or deactivate the key touch sound� A check
mark (√) indicates that the menu option is activated�
Factory Settings:
Select the "Factory settings" option, the system requests confirmation to restore the factory
settings� Press "OK" button to reset all the system settings to the original standard values set at
dispatch from the factory (see "Menu structure")�
Information:
The "Information" option offers you an overview of the most important system settings of the
device�
28

Interfaces and outputs

The device can be connected to a PC and operated with the laboratory software labworldsoft
through USB or RS 232 interface�
The device software can also be updated with a PC via the RS 232 or USB port�
Note: Please comply with the system requirements together with the operating instructions
and help section included with the software�
RS 232
USB 2.0
type B
/// USB interface
The Universal Serial Bus (USB) is a serial bus for connecting the device to the PC� Equipped
with USB devices can be connected to a PC during operation (hot plugging)�
Connected devices and their properties are automatically recognized�
Use the USB interface in conjunction with labworldsoft
also to update the firmware�
/// USB device drivers
First, download the latest driver for IKA devices with USB interface from:
www.ika.com/ika/lws/download/usb-driver.zip.
Install the driver by running the setup file� Connect the IKA device through the USB data cable
to the PC� The data communication runs through a virtual COM port�
Note: the USB driver is uncessary for Windows 10 system� Don't install it for Windows 10
system!
®
for operation in "Remote" mode and
®
29
