  • Page 1 IKA MATRIX DELTA PLUS...
  • Page 2 ENGLISH...
  • Page 3: Table Of Contents

    EU Declaration of conformity ����������������������������������������������������������������������� 6 Explication of warning symbols �������������������������������������������������������������������� 6 Safety instructions ���������������������������������������������������������������������������������������� 7 Intended use ������������������������������������������������������������������������������������������������ 9 Unpacking ������������������������������������������������������������������������������������������������� 10 Operator panel and display ������������������������������������������������������������������������ 11 Installation �������������������������������������������������������������������������������������������������13 Fig. 1 Operation ��������������������������������������������������������������������������������������������������17 Menu navigation and structure ������������������������������������������������������������������ 23 Interfaces and outputs �������������������������������������������������������������������������������...
  • Page 4: Eu Declaration Of Conformity

    › Read the operating instructions completely before starting up and follow the safety instructions. A copy of the complete EU Declaration of conformity can be requested at sales@ika�com� › Keep the operating instructions in a place where it can be accessed by everyone�...
  • Page 5: Intended Use

    › Covers or parts that can be removed from the device without tools must later be refitted to The MATRIX DELTA PLUS device is used for tempering liquids in closed tubes and closed ensure safe operation� This will prevent the infiltration of foreign objects, liquids and other plates in the preparation of samples�...
  • Page 6: Operator Panel And Display

    Touch it once: Pause the tempering function� Pause (II) button Touch it a second time: Restart the tempering function� Start / stop the tempering function� Tempering button IKA MATRIX DELTA PLUS User guide Confirm the select menu option in menu / sub-menu� Power cable Warranty card Decrease the temperature setting�...
  • Page 7: Installation

    Indicate the device is in program control mode� Power failure symbol Indicate a previous power supply interruption� IKA ThermoCover Symbol Indicate IKA ThermoCover is attached to the device� Note: The symbols displayed change depending on the status and settings of the device�...
  • Page 8 /// Attaching the exchangeable attachments /// Inserting deepwell plate (DWP) / the microplate (MTP) /// Inserting the micro test tubes Click...
  • Page 9: Operation

    /// Attaching the IKA Cover / IKA ThermoCover Operation /// Switching on Shaker IKA MATRIX Delta + Version: 1.02.003/1.01.021 IKA MATRIX 2.0 mL 0:00:00 25.0 Fast actual ºC Set ºC Note: After the contact of the ThermoCover cover has been established with the device by...
  • Page 10 /// Setting the temperature and start tempering function /// Pausing the tempering function IKA MATRIX 2.0 mL IKA MATRIX 2.0 mL 0:00:30 0:00:00 38.0 25.0 Fast actual ºC Fast actual ºC 38.0 Set ºC Set ºC  100.0 IKA MATRIX 2.0 mL IKA MATRIX 2.0 mL...
  • Page 11 /// Restarting the tempering function /// Locking the buttons IKA MATRIX 2.0 mL IKA MATRIX 2.0 mL 0:00:30 0:00:50 28.0 38.0 Fast actual ºC Fast actual ºC 38.0 38.0 Set ºC Set ºC IKA MATRIX 2.0 mL IKA MATRIX 2.0 mL...
  • Page 12: Menu Navigation And Structure

    /// Unlocking the buttons Menu navigation and structure /// Menu navigation IKA MATRIX 2.0 mL 0:00:51 38.0 Fast actual ºC 38.0 › Press the “Menu” button (D)� Set ºC › Select the right menu item by touching the temperature (+) button (I)�...
  • Page 13 /// Menu structure /// Menu details Factory setting Tempering Control rate Fast √ Tempering: Moderate Control rate: Slow In the "Control rate" menu option, you can select the desired control rate between "Fast", "Mod- erate" and "Slow"� A check mark (√) indicates the control rate is activated� Timer Timer / Counter 00:00:00 [hh:mm:ss]...
  • Page 14 In control mode "± x�x K": The hysteresis (tolerance) of the actual temperature to target Graph: temperature is set (e�g� ± 0�1 K)� The target values and settings of the segment are valid until the actual temperature reaches the target temperature +/- hysteresis for the first time� X - Axis: Afterwards, the next program segment is automatically executed�...
  • Page 15: Interfaces And Outputs

    First, download the latest driver for IKA devices with USB interface from: www.ika.com/ika/lws/download/usb-driver.zip. Install the driver by running the setup file� Connect the IKA device through the USB data cable to the PC� The data communication runs through a virtual COM port�...
  • Page 16 1�1)� tempering functions are switched off and Error 2 is displayed� The NAMUR commands and the additional specific IKA commands serve only as low level commands for communication between the device and the PC� With a suitable terminal or “Watchdog”...
  • Page 17 Solutions › Switch off and restart the device� After registering your device IKA will inform you about available updates for your devices� › Send device for repair if the error message appear again� Please download the software "FWUToolSetup�zip" from our IKA service website www.ika.com�...
  • Page 18: Maintenance And Cleaning

    › Software version (Briefly visible in the display when the device is switched on)� 1 x DWP For IKA PCR 96, IKA PCR 384, IKA 0�5 ml, IKA 1�5 ml, IKA 2�0 ml and IKA CARRIER (MTP & DWP)� /// Repairs...
  • Page 19: Technical Data

    IP code according to EN 60529 IP 21 In accordance with IKA warranty conditions, the warranty period is 24 months� For claims under the warranty please contact your local dealer� You may also send the machine direct to our factory, Safety class enclosing the delivery invoice and giving reasons for the claim�...
  • Page 20 VIETNAM IKA Vietnam Company Limited Phone: +84 28 38202142 eMail: sales�lab-vietnam@ika�com Discover and order the fascinating products of IKA online: www.ika.com IKAworldwide IKAworldwide /// #lookattheblue @IKAworldwide Technical specifications may be changed without prior notice�...
