- Page 1 GREENHOUSE BENCH KITS PolyMax® Bench System Extension For use with the 108293S Bench System All Rights Reserved. Reproduction is prohibited without permission. SKU# DIMENSIONS 108293SE 4' W x 8' L x 30" H (extension) Revision date: 10.26.21...
- Page 2 GREENHOUSE BENCH KITS REQUIRED TOOLS The following list identifies the main tools needed to assemble the feed bunk. Additional tools may be needed. • Tape measure or measuring device • Marker READ THIS DOCUMENT BEFORE YOU • Variable speed drill and impact driver (cordless with BEGIN TO ASSEMBLE THE BENCH.
- Page 3 GREENHOUSE BENCH KITS The following graphics and photos will help you identify the different parts of the bench. Square Tube SKU# Cut Length Quantity S15P044 1.5" x 1.5" x 44" 102897 1.5" x 1.5" x 99" S15P092 1.5" x 1.5" x 92" S20P028 2"...
- Page 4 GREENHOUSE BENCH KITS Before assembling the bench extension, layout and measure the 1.5" x 1.5" square tube lengths to verify that you have all the correct tubes. Determine the end of the original bench where the extension will be attached. Remove the Tek screws that secure the Polymax®...
- Page 5 GREENHOUSE BENCH KITS Gather one (1) 92" tube and one (1) one-way plate (#104624). Center a one-way plate on the end of the assembled bench as shown below. Attach using a Tek screw on each side of the plate. Slide a 92" tube into the fitting and secure with a Tek screw. Original Bench (sold separately) One-way Plate...
- Page 6 GREENHOUSE BENCH KITS Gather one (1) 44" tube, two (2) 2-way corner fittings, and one (1) 3-way fitting. Slide the 44" tube through the 3-way fitting first, and then assemble as shown below. Do not attach 3-way fitting at this time. Verify the outside-to-outside dimension is 48"...
- Page 7 GREENHOUSE BENCH KITS Carefully (and with assistance) flip the frame onto its legs. Use a sawhorse or some other stable object to prop the assembled extension frame so it is level with the original bench frame for the time being. Gather four (4) PolyMax®...
- Page 8 GREENHOUSE BENCH KITS Gather two (2) one-way plates (104624). Measure and mark a line 6-1/2" from each corner edge on the 99" tubes. Position the edge of a one-way plate on this line and attach to the 99" tube using Tek screws on each side of the plate.
- Page 9 GREENHOUSE BENCH KITS Gather two (2) 28" lengths of 2" x 2" tube. Slide a 28" tube over each one-way plate and secure as shown below using one Tek screw per leg. Original Bench (sold separately) 28" Tube Tek screw 28"...
- Page 10 GREENHOUSE BENCH KITS Gather two (2) 53" lengths of aluminum strap (112480Z53). Measure 3" from each end of each leg. At these points, secure the aluminum straps to the legs as shown below using Tek screws. ATTENTION: Verify that the legs are straight before attaching the aluminum straps. Original Bench 3"...
- Page 11 GREENHOUSE BENCH KITS Gather two (2) 29" lengths of aluminum strap (112480Z29). Secure a strap to each corner as shown below using Tek screws. 24" Tek screw SIDE VIEW Tek screw 4-1/2" Original Bench (sold separately) Bench Extension COMPLETED BENCH EXTENSION FRAME Revision date: 10.26.21...
- Page 12 GREENHOUSE BENCH KITS Gather four (4) PolyMax® (#HA2217) panels for the bench top. Set the PolyMax® panels in place as shown and square them on the frame. Using the mounting holes in the panels, secure them to the frame using 117413 flat screws. Do not overtighten. Screws should be snug. Verify that flat screw tops are flush with the PolyMax®...
- Page 13 GREENHOUSE BENCH KITS Original Bench Frame with Extension Dimensions Outside-to-Outside 192-1/2" Outside-to-Outside 30" 48" Revision date: 10.26.21...
