Installation
4.4

Digital Input

The digital input can be used to control roaming between Bluetooth access points (NAP). For
more information, refer to the AT Reference Guide at www.anybus.com/support.
4.5

RESET Button

Fig. 4 RESET button
The RESET button is located on the bottom of the unit.
When the unit is powered on, press and hold RESET for >10 seconds and then release it to reset
to the factory default settings.
Recovery Mode
If the web interface cannot be accessed, the unit can be reset by starting in Recovery Mode and
reinstalling the firmware using Anybus Firmware Manager II, which can be downloaded from
www.anybus.com/support.
To enter Recovery Mode, press and hold RESET during startup.
® ™
Anybus Wireless Bolt CAN User Manual
If voltage is applied to the digital input for more that 10 seconds the unit will be reset to
factory defaults.
Firmware updates should normally be carried out through the web interface. Recovery
Mode should only be used if the unit is unresponsive and the web interface cannot be
accessed.
