Package Contents
One ZyPer4K Quad Encoder Card
Four IR Emitters
One IR Receiver
IR Emitter (4x)
Z4K Quad Encoder
Infrared Commands passed back FROM decoders as configured by ZMP.
Infrared Commands passed back FROM decoders as configured by ZMP.
Infrared Commands passed back FROM decoders as configured by ZMP.
Infrared Commands to be passed TO decoders as configured by ZMP.
Hardware Reset pin. Use paperclip or other tool to hold internal button for 25
seconds to force reset of the Z4KNGENC4 to factory defaults. See Appendix A
for details.
Quad Encoder Card
Page
2
of
11
IR Receiver (1x)
