  • Page 1 ZyPer4K 4K IP Video Distribution System —————————————————————————————————————————— User Manual Updated July 2024
...
  • Page 2 ZeeVee is the leading manufacturer of high-quality encoder/modulator/decoder products for video distribution over any type of transmission media; be it RF coax, fiber, or copper ethernet. Established in 2007, ZeeVee has been manufacturing industry-leading products while operating the company responsibly in compliance with the strictest levels of regulatory and environmental requirements.

  • Page 3: Table Of Contents

    CONTENTS System Description ..................1 System Elements .....................2 Encoder Function .....................2 Decoder Function .....................3 Management Platform ...................5 ZyPer Management Platform Hardware ............6 Detailed Interface Descriptions ..............7 Encoder ........................7 Enclosure variants ..................7 Common Ports ....................7 Optional Ports - 10Gb Ethernet ..............9 Optional Ports - USB .................10 Extended Input Options ................11 XS Version Encoders ..................17 ZyPer4K-XS Encoder Reset Pin ...............23...
  • Page 4 Enclosure variants ..................36 Common Ports ...................36 Optional Ports: 10Gb Ethernet ..............38 Optional Ports: USB ..................39 Optional Ports: Display Port ..............39 Quiet/Fanless Decoder ................40 XS Version Decoders ..................41 ZyPer4K-XS Decoder Reset Pin ..............47 XR Version Decoders ................48 ZyPer4K-XR Decoder Mounting Hole and Reset Pin ......51 Wallplate Decoder (US form factor-front) ...........52 Wallplate Decoder (US form factor-back) ............53 Wallplate Decoder (EU form factor-front) ...........55...
  • Page 5 General Safety and Care Instructions ............77 Safety ........................77 Cleaning ........................79 Encoder, Decoder and ZyPerMP Unit Cleaning Procedures ...79 ZyPerMP Specific Cleaning Procedure ..........80 Important Siting and Application Considerations ........81 ZyPer4K Equipment Type and Uses ..............81 Installation Environment ..................82 Mounting Options ..................82 Mounting Brackets ..................82 VESA Mounting Bracket ................85 Ventilation ....................87...
  • Page 6 Appendix 2 ....................104 USB-C Charging ....................104 USB-C Cable Requirements ..............104 Appendix 3 ....................105 PoE Power and PoE Switches ................105 Why Shielded Ethernet Cable Is Required .............106 Appendix 4 ....................108 Accessories ......................108 Appendix 5 ....................110 ZyPer4K Part Numbers ..................110 Disclaimers ....................115...

  • Page 7: System Description

    ZyPer4K System Description The ZyPer4K series of products from ZeeVee provide a means for transmitting and receiving up to 4K audio-visual information across a standard 10Gb IP network with outstanding quality at very low latencies. A minimal system consists of: •...

  • Page 8: System Elements

    ZyPer4K System Elements Encoder Function The function of the ZyPer4K Encoder Device (Encoder) is to accept audio and video data over a variety of interface types, and translate that data to a format suitable for transmission over a standard 10Gb Ethernet network. Video data is segmented, encrypted, prepared for transmission, and sent by the Encoder unit.

  • Page 9: Decoder Function

    ZyPer4K HDMI Copper 12G-SDI Copper DisplayPort Analog Copper Dual HDMI with Copper Loopback Copper HDMI Copper 12G-SDI Copper DisplayPort Analog Copper Dual HDMI with with USB w/USB Copper w/USB with USB Loopback Copper w/USB XS Copper with XS Fiber with XR Copper with XR Fiber XR Fiber (single mode)
  • Page 10 ZyPer4K In total there are 25 different, unique Decoder types that can be ordered. HDMI Fiber HDMI Fiber with USB HDMI Copper HDMI Copper with USB DisplayPort Fiber DisplayPort Fiber with DisplayPort Copper DisplayPort Copper with HDMI Fiber (Quiet/ HDMI Copper (Quiet/ HDMI Copper with USB HDMI Fiber with USB Fanless)

  • Page 11: Management Platform

    Operation of the ZyPerMP, the Management application, and the ZyPer-API are beyond the scope of this manual and are documented separately in far greater detail in the ZyPer Management Platform User Manual. Documentation can be downloaded from the ZeeVee website.

  • Page 12: Zyper Management Platform Hardware

    ZyPer4K ZyPer Management Platform Hardware The ZyPer Management Platform (ZMP) is available from ZeeVee in two different hardware options.  NUC and Rack Mount Server.  Both versions have two network interfaces.  It is important that the port labeled “Video Network” is connected to the LAN containing the ZyPer4K encoder/decoder endpoints. ...

  • Page 13: Detailed Interface Descriptions

    ZyPer4K Detailed Interface Descriptions Encoder The function of the encoder is to accept raw video images, encode, encrypt and format them for transmission. There are several different variations based on the user’s desired input, media type and interface description. The encoder supports inputs up to 4K resolution including full HDMI 2.0 support.
  • Page 14 ZyPer4K Port Name Index Definition Power 12VDC from supply. Center Post is + Ring is - Utility 10/100/1000Base-T Ethernet port. Used for general purpose Network device attachment to network. Traffic will be switched on to media network. Ground Lug For equipotential referencing of the box, this lug may be connected the environmental ground using a customer-supplied ground lead.

  • Page 15: Optional Ports - 10Gb Ethernet

    Direction of port configured by ZMP. IR-OUT Infrared commands information passed back FROM decoders as configured by ZMP. Note: Must user ZeeVee part number Z4KIRTX IR-IN Infrared commands to be passed TO decoders as configured by ZMP. Note: Must use ZeeVee part number Z4KIRRX RESET Reset to factory defaults.

  • Page 16: Optional Ports - Usb

    ZyPer4K Optional Ports - USB ZyPer4K Encoder units are available with or without a USB port. Note: Information below does not pertain to XS Encoder units. Port Name Index Definition USB 2.0 Type B port. Configuration and routing of USB handled by the ZMP configuration.

  • Page 17: Extended Input Options

    ZyPer4K Extended Input Options All Encoder units contain a single HDMI 2.0 input port. Optionally, units may be ordered with an “extended” input. Units so ordered will reside in a somewhat larger enclosure. Available interface types are shown: (note: All input types are available with either 10Gb Fiber or 10Gb Copper...
  • Page 18 ZyPer4K Port Name Index Definition ZeeVee 13-Pin High density DIN connector allows for all signals related to Analog Video Hydra to be input. Types of Hydra Cable supported: • Connection Analog Video (YPrPb + S/PDIF + CVBS + LR Audio) •...
  • Page 19 ZyPer4K DisplayPort Input Option The ZyPer4K Encoder may be purchased with the “DisplayPort Input Option” pre-installed at the factory. Type Parameter DisplayPort Option Single DisplayPort receptacle support v1.2a of the DisplayPort standard. Direction Input Resolutions Same complete set of resolutions as supported by the resident HDMI module on the core Encoder unit.
  • Page 20 ZyPer4K “12G-SDI” Option The ZyPer4K Encoder can be purchased with the commonly referred-to “12G-SDI Option”. Note that the 3G-SDI Option has been discontinued as of mid 2023. Type Parameter 12G-SDI Option Single Input port supporting the following standards: SMPTE 259M-C, ST292-1, ST424, ST2081-1, ST2082-1 LoopThrough Retimed, re-amplified, direct-copy of the input signal provided on the “Loop”...
  • Page 21 ZeeVee Hydra cable connected to the 13-pin DIN jack. Analog Audio (VGA-type 2-channels of line-level L/R analog stereo input through 3.5mm plug DIN cable) spawned by the VGA version of the ZeeVee Hydra cable connected to the 13-Pin DIN jack. Rev: 20240717 Page User Manual...
  • Page 22 ZyPer4K Type Parameter Digital Audio When S/PDIF connection of the ZeeVee Hydra analog breakout cable is employed, received audio can be 2-channels of LPCM, or digitally encoded. If digitally encoded audio is received, it will be passed through unmodified through the Z4K system to the decoders (see HDMI Port specification).

  • Page 23: Xs Version Encoders

    ZyPer4K Two different variants of the ZeeVee Hydra breakout cable may be purchased separately for use in the specific user application VGA BREAKOUT • HD-15 supporting numerous resolutions up to 1900x1600 • Analog audio input carrying stereo L/R line-level audio for transport.
  • Page 24 ZyPer4K ZyPer4K XS Encoder (Copper) Port Name Index Definition Power 12VDC from supply. Center Post is + Ring is - 10G Copper 10Gb Ethernet over Cat6a (or better) cabling. RJ45. Supports PoE.
 (PoE)
 Important Note: If using PoE with ZyPer4K units; the ZyPer4K must have a path to the ground.
  • Page 25 ZyPer4K ZyPer4K XS Encoder (Fiber) Port Name Index Definition Power 12VDC from supply. Center Post is + Ring is - 10G Fiber 10 Gigabit Ethernet Connection. Uses standard 10Gb pluggable devices SFP devices. Utility 10/100/1000Base-T Ethernet port. Used for general purpose device Network attachment to network.
  • Page 26 ZyPer4K ZyPer4K XS Encoder with USB-C (Copper) Note: Dante/Icron is optional feature Port Name Index Definition Power 12VDC from supply. Center Post is + Ring is - 10G Copper 10Gb Ethernet over Cat6a (or better) cabling. RJ45. Supports PoE.
 (PoE)
...
  • Page 27 ZyPer4K ZyPer4K XS Encoder with USB-C (Fiber) Note: Dante/Icron is optional feature Port Name Index Definition Power 12VDC from supply. Center Post is + Ring is - 10G Fiber 10 Gigabit Ethernet Connection. Uses standard 10Gb pluggable devices SFP devices. Utility 10/100/1000Base-T Ethernet port.
  • Page 28 ZyPer4K Important Note (Optional Dante/Icron module for XS encoder units)
 The Optional Dante/Icron USB system requires its own IP Address that is different and independent from the IP Address of the ZyPer4K-XS itself. Therefore a ZyPer4K-XS unit with Dante and Icron USB needs three IP addresses. Customers that are using a DHCP server to generate IP Addresses must ensure the pool of available IP Addresses accounts these extra devices needing IP Addresses in the system.

  • Page 29: Zyper4K-Xs Encoder Reset Pin

    ZyPer4K ZyPer4K-XS Encoder Reset Pin The hardware reset pin for the ZyPer4K-XS encoder is located on the side of the unit with the regulatory markings. (Note image below enhanced to better show the location of the reset pin hole. There is no white circle around the reset pin hole.) Port Name Index Definition RESET...
  • Page 30 ZyPer4K ZyPer4K XR Encoder (Copper) Port Name Index Definition 10G Copper 10Gb Ethernet over Cat6a (or better) cabling. RJ45. Supports PoE.
 (PoE)
 Important Note: If using PoE with ZyPer4K units; the ZyPer4K must have a path to the ground. This grounding can be accomplished by using a shielded network cable (F/UTP).
  • Page 31 ZyPer4K ZyPer4K XR Encoder (Fiber) Fiber Gasket Port Name Index Definition 10G Fiber 10Gb Ethernet over Fiber. LC connector. (Neutrik N02-4FDW-1-A) Multimode or Single mode. SFP module integrated into the unit. (MMF Gasket = Black, SMF Gasket = Yellow) Note: MMF supports 50um fiber cable only Utility 10/100/1000Base-T Ethernet port.

  • Page 32: Zyper4K-Xr Encoder Mounting Hole And Reset Pin

    ZyPer4K ZyPer4K-XR Encoder Mounting Hole and Reset Pin The hardware reset pin for the ZyPer4K-XR encoder is located on the side of the unit with the Stage-Clamp Mount Point. (Note image below enhanced to better show the location of the reset pin hole.

  • Page 33: Wallplate Encoder (Us Form Factor-Front)

    ZyPer4K Wallplate Encoder (US form factor-front) Port Name Port Name Index Definition Utility 10/100/1000Base-T Ethernet port. Used for general purpose device Network attachment to network. Audio Audio Input/Output Jack. Drives line-level stereo audio. USB-B USB 2.0 Type B port. Configuration and routing of USB handled by the ZMP configuration.

  • Page 34: Usb-C Cable Requirements

    8. Must have built in E-Mark IC Please see Appendix 1 near the end of this document for a list of known good USB-C cables. ZeeVee is not responsible for damage to any equipment caused by poor or incorrect USB-C cables.
  • Page 35 It is important to remember that the ZyPer4K wallplate is a device that requires a 10Gb network. Therefore any PoE injector must also support 10Gb data transfer. ZeeVee recommends the following 10G PoE Injector for use with the ZyPer4K wallplate and ZyPer4K-XS copper units.
  • Page 36 ZyPer4K Cable state changes • HDMI connected; USB not connected but USB-C is then connected – Video remains HDMI • USB-C is connected; HDMI is not connected but HDMI is then connected- Video changes to HDMI • Any cable pulls at this point the video will fail over to the other active source.  ...

  • Page 37: Wallplate Encoder (Eu Form Factor-Front)

    ZyPer4K Wallplate Encoder (EU form factor-front) Port Name Port Name Index Definition Utility 10/100/1000Base-T Ethernet port. Used for general purpose device Network attachment to network. Audio Audio Input/Output Jack. Drives line-level stereo audio. USB-B USB 2.0 Type B port. Configuration and routing of USB handled by the ZMP configuration.

  • Page 38: Usb-C Cable Requirements

    8. Must have built in E-Mark IC Please see Appendix 1 near the end of this document for a list of known good USB-C cables. ZeeVee is not responsible for damage to any equipment caused by poor or incorrect USB-C cables.

  • Page 39: Wallplate Encoder (Eu Form Factor-Back)

    It is important to remember that the ZyPer4K wallplate is a device that requires a 10Gb network. Therefore any PoE injector must also support 10Gb data transfer. ZeeVee recommends the following 10G PoE Injector for use with the ZyPer4K wallplate and ZyPer4K-XS copper units.
  • Page 40 ZyPer4K Connected = Active source • Both HDMI and USB-C disconnected – no link • USBC disconnected, HDMI is connected – Wall Plate HDMI is connected • HDMI disconnected; USB-C is connected – Wall Plate connects USB-C   Cable state changes •...

  • Page 41: Important Usb-C Information

    7. Must have built in E-Mark IC Please see Appendix 1 near the end of this document for a list of known good USB-C cables. ZeeVee is not responsible for damage to any equipment caused by poor or incorrect USB-C cables.

  • Page 42: Decoder

    ZyPer4K Decoder The function of the ZyPer4K Decoder is to accept a 10Gb IP feed containing the video information to be displayed. It decrypts, decodes and formats the video and audio information for display on the attached viewing device. The decoder is capable of outputting any HDMI 2.0 resolution supplied by the encoder including full 4K, 4:4:4 at 60Hz.
  • Page 43 ZyPer4K Port Name Index Definition Power 12VDC from supply at 1.2A (center +, ring-) Utility 10/100/1000Base-T Ethernet port. Used for general purpose Network device attachment to network. Traffic will be switched on to media network. Ground Lug For equipotential referencing of the box, this lug may be connected the environmental ground using a customer-supplied ground lead.

  • Page 44: Optional Ports: 10Gb Ethernet

    Definition IR-OUT Infrared Commands information passed FROM Encoders to Decoders as configured by ZMP. Note: Must user ZeeVee part number Z4KIRTX IR-IN Infrared Commands to be passed TO Encoders as configured by ZMP. Note: Must user ZeeVee part number Z4KIRRX RESET Reset to factory defaults.

  • Page 45: Optional Ports: Usb

    ZyPer4K Optional Ports: USB The ZyPer4K Decoder device can be ordered with optional USB connectivity. Shown to the left is a unit with the USB option (top) and without the USB option (bottom) installed. This is a build-time option and is not retrofittable to the product.

  • Page 46: Quiet/Fanless Decoder

    ZyPer4K Quiet/Fanless Decoder The Quiet/Fanless decoder is available with either Copper or Fiber connectivity. Note that USB is not available with this version of hardware. (Note this product is discontinued) Port Name Index Definition HDMI Output HDMI 2.0 Output port. Capable of up to 4K60 4:4:4 with embedded audio and HDCP2.2 encryption.

  • Page 47: Xs Version Decoders

    ZyPer4K Port Name Index Definition RS 232 Port RS232 Control Port for sending and receiving side-band serial traffic to/from encoders as directed by ZyPer Management Platform. (ZMP) LED PWR LED illuminated when unit is powered LED VID LED Illuminated when active video is being processed Audio Audio Output Jack.
  • Page 48 ZyPer4K ZyPer4K-XS Decoder (Copper) Port Name Index Definition Power 12VDC from supply. Center Post is + Ring is - 10G Copper 10Gb Ethernet over Cat6a (or better) cabling. RJ45. Supports PoE.
 (PoE)
 Important Note: If using PoE with ZyPer4K units; the ZyPer4K must have a path to the ground.
  • Page 49 ZyPer4K ZyPer4K-XS Decoder (Fiber) Port Name Index Definition Power 12VDC from supply. Center Post is + Ring is - 10G Fiber 10 Gigabit Ethernet Connection. Uses standard 10Gb pluggable devices SFP devices. Utility 10/100/1000Base-T Ethernet port. Used for general purpose device Network attachment to network.
  • Page 50 ZyPer4K ZyPer4K-XS Decoder with RS-232 (Copper) Note: Dante/Icron is Optional Feature Port Name Index Definition Power 12VDC from supply. Center Post is + Ring is - 10G Copper 10Gb Ethernet over Cat6a (or better) cabling. RJ45. Supports PoE.
 (PoE)
...
  • Page 51 ZyPer4K ZyPer4K-XS Decoder with RS-232 (Fiber) Note: Dante/Icron is Optional Feature Port Name Index Definition Power 12VDC from supply. Center Post is + Ring is - 10G Fiber 10 Gigabit Ethernet Connection. Uses standard 10Gb pluggable devices SFP devices. Utility 10/100/1000Base-T Ethernet port.
  • Page 52 ZyPer4K Important Note (Optional Dante/Icron module for XS decoder units)
 The Optional Dante/Icron USB system requires its own IP Address that is different and independent from the IP Address of the ZyPer4K-XS itself. Therefore a ZyPer4K-XS unit with Dante and Icron USB needs three IP addresses. Customers that are using a DHCP server to generate IP Addresses must ensure the pool of available IP Addresses accounts these extra devices needing IP Addresses in the system.

  • Page 53: Zyper4K-Xs Decoder Reset Pin

    ZyPer4K ZyPer4K-XS Decoder Reset Pin The hardware reset pin for the ZyPer4K-XS decoder is located on the side of the unit with the regulatory markings. (Note image below enhanced to better show the location of the reset pin hole. There is no white circle around the reset pin hole.) Port Name Index Definition RESET...

  • Page 54: Xr Version Decoders

    ZyPer4K XR Version Decoders XR version decoders provide a rugged enclosure with rugged connections options as well as silent fanless operation. Note that XR version decoders and standard encoders/decoders are compatible with each other with the exception of a few features noted below: XR Version decoders do not support RS232 or IR ports.
  • Page 55 ZyPer4K ZyPer4K XR Decoder (Copper) Port Name Index Definition 10G Copper 10Gb Ethernet over Cat6a (or better) cabling. RJ45. Supports PoE.
 (PoE)
 Important Note: If using PoE with ZyPer4K units; the ZyPer4K must have a path to the ground. This grounding can be accomplished by using a shielded network cable (F/UTP) or the connected HDMI display is grounded.
  • Page 56 ZyPer4K ZyPer4K XR Decoder (Fiber) Fiber Gasket Port Name Index Definition 10G Fiber 10Gb Ethernet over Fiber. LC connector. (Neutrik N02-4FDW-1-A) Multimode or Single mode SFP module integrated into the unit. (MMF Gasket = Black, SMF Gasket = Yellow) Note: MMF supports 50um fiber cable only Utility 10/100/1000Base-T Ethernet port.

  • Page 57: Zyper4K-Xr Decoder Mounting Hole And Reset Pin

    ZyPer4K ZyPer4K-XR Decoder Mounting Hole and Reset Pin The hardware reset pin for the ZyPer4K-XR decoder is located on the side of the unit with the Stage-Clamp Mount Point. (Note image below enhanced to better show the location of the reset pin hole.

  • Page 58: Wallplate Decoder (Us Form Factor-Front)

    ZyPer4K Wallplate Decoder (US form factor-front) Port Name Port Name Index Definition Utility 10/100/1000Base-T Ethernet port. Used for general purpose device Network attachment to network. Audio Audio Output Jack. Drives line-level stereo audio. USB-A USB 2.0 Type A ports. Configuration and routing of USB handled by the ZMP configuration.

  • Page 59: Wallplate Decoder (Us Form Factor-Back)

    ZyPer4K Port Name Index Definition Reset Reset to factory defaults. Disconnect power. Delete unit from ZMP GUI. Using a wire or paper clip, lightly press into this hole while powering on the unit. Hold for 15 seconds to reset the unit to factory defaults. (Note reset hole highlighted in drawing above.
  • Page 60 ZyPer4K ZeeVee recommends the following 10G PoE Injector for use with the ZyPer4K wallplate and ZyPer4K-XS copper units. Procet PT-PSE104GB-60-10 To support PoE the following minimum Ethernet cable requirements must be met.   • Must be Cat6a 23AWG Solid Copper Twisted Pair.

  • Page 61: Wallplate Decoder (Eu Form Factor-Front)

    ZyPer4K Wallplate Decoder (EU form factor-front) Port Name Index Definition Utility 10/100/1000Base-T Ethernet port. Used for general purpose device Network attachment to network. Audio Audio Output Jack. Drives line-level stereo audio. USB-A USB 2.0 Type A ports. Configuration and routing of USB handled by the ZMP configuration.

  • Page 62: Wallplate Decoder (Eu Form Factor-Back)

    It is important to remember that the ZyPer4K wallplate is a device that requires a 10Gb network. Therefore any PoE injector must also support 10Gb data transfer. ZeeVee recommends the following 10G PoE Injector for use with the ZyPer4K wallplate and ZyPer4K-XS copper units.
  • Page 63 ZyPer4K • DC Resistance Unbalance per Pair 3% or < 200mΩ Important Note If using a Network Switch to provide PoE power to the ZyPer4K devices, it is important that the switch itself be protected against electrical surges that could be caused by something like a lightning strike.

  • Page 64: Options

    ZyPer4K Options Most ZyPer4K Encoders or Decoders can me ordered with a single 10G bulk media port that is either Fiber Ethernet or Copper Ethernet. Only one of those options is supported at a given time. (Wallplate units available as Copper only) Type Encoder Decoder...
  • Page 65 2-channel L/R stereo output Note: Updated XS units support 5-pin phoenix connector ✓ ✓ IR Input 3.5mm plug for IR Capture Dongle (ZeeVee Model#: Z4KIRRX ) ** capture dongle sold separately ✓ ✓ IR Output 3.5mm plug for IR Transmitter (ZeeVee Model#:...

  • Page 66: Setting Up Zyper4K In A Point To Point Environment

    ZyPer4K Setting Up ZyPer4K in a Point to Point Environment A point to point, or one to one environment involves connecting one source directly to one display. A network switch is not needed in this basic configuration. This environment also does not require configuration through the ZyPer4K management software and is a true “plug and play”...

  • Page 67: Dante Embedded Platform (Dep)

    ZyPer4K Dante Embedded Platform (DEP) Some ZyPer4K Encoders and Decoders support DEP. This means every endpoint can be configured to support both Dante transmission and receive functionality. Feature Supported/Descrip0on Dante Audio channels 2x2 (input x output) Sample rate 44.1, 48, 88.2, 96 kHz Audio format LPCM only PCM sample format...
  • Page 68 ZyPer4K Critical Note: For Dual LAN configuration. The Dante LAN port and Primary Z4K 10G LAN port should never be on the same subnet. This will cause IP conflicts that could result in video not properly flowing on the network. (Note this means that you cannot have both ports set to a Link-Local address.

  • Page 69: Dante Operation

    ZyPer4K Dante Operation It is expected that the user is familiar with Dante and the use of Dante networks. It is beyond the scope of this document to provide Dante training. The Dante Transmitter found in the ZyPer4K encoder/decoder will insert the analog audio or HDMI audio stream that it is receiving onto the Dante Network.
  • Page 70 ZyPer4K Dante Status Rev: 20240717 Page User Manual...
  • Page 71 ZyPer4K Important Note: The Sample Rate must be set to the correct rate of the incoming audio. Incorrect setting of the Sample Rate field will cause a Dante Transmitter to not see audio as available to transmit. Incorrect setting of the Sample Rate field will cause a Dante Receiver to not receive audio from a Dante Transmitter.

  • Page 72: Dante Api Commands

    ZyPer4K Dante API Commands The following are important API commands related to Dante operation on supported ZyPer4K- XS Encoders and Decoders. To have Dante on the primary 10G Network API Command: set device NAME utilityPort enabled (Note can also set this from ZMP GUI. See images below) To have Dante on the 1G Utility port (Separate LAN) API Command: set device NAME utilityPort onlyDanteAudio...
  • Page 73 ZyPer4K Decoder Commands Receive Function set decoder DEC_NAME analogAudioOut source directDanteAudio set decoder DEC_NAME hdmiAudioOut source directDanteAudio Note: You can use both commands above at the same time. This will provide Dante audio out from both HDMI and Analog Audio Ports
 Rev: 20240717 Page User Manual...

  • Page 74: Setting Up Zyper4K In Many To Many Environment

    ZyPer4K Setting up ZyPer4K in Many to Many Environment A many to many, or switched environment involves connecting many sources to many displays. ZyPer4K allows you a flexible and scalable amount of input-output options without limitations.
 For example, in a 24-port configuration, you can configure a 1x23, 6x18, or 4x20 (and so on) system.
  • Page 75 ZyPer4K • Switch (or route) video from sources to displays • Drag source onto display to route video/audio IP Address of MP Drag and Drop Rev: 20240717 Page User Manual...
  • Page 76 Please consult the ZyPer Management Platform User Manual for additional details on switching/routing video from sources to displays. Please consult the ZyPer4K Network Requirements and Security Considerations document for details on Network switch requirements. Both documents are available on the ZeeVee website: https://www.zeevee.com/documentation Rev: 20240717 Page...

  • Page 77: Icron Usb Details (Optional Feature Most Units)

    ZyPer4K Icron USB Details (Optional Feature most units) The ZyPer4K provides for USB-over-LAN communications using an optional Icron chipset. The ZyPer4K Encoder contains a 4-port USB Hub while the ZyPer4K decoder contains a USB Host. This configuration provides support for connecting an Encoder to up to 4 Decoders. The total number of connected USB devices is limited to USB bandwidth.

  • Page 78: Usb Details (Standard Feature Xs/Xr Units)

    ZyPer4K USB Details (Standard Feature XS/XR units) The ZyPer4K provides for USB-over-LAN communications. The ZyPer4K Encoder contains a USB Device Port while the ZyPer4K decoder contains a USB Host. This configuration provides support for connecting an Encoder to a single Decoder. The total number of connected USB devices is limited to 2 per decoder.

  • Page 79: Technical Specifications

    ZyPer4K Technical Specifications Encoder and Decoder HDMI Video Specifications All encoders and decoders have one exposed HDMI port. It is an input on the encoder and an output on the decoder. All the parameters in terms of the formats of video and audio carried are the same for either.

  • Page 80: Decoder Displayport Video Specifications

    ZyPer4K HDMI ZyPer4K ✓ ✓ HDMI Audio All encoded audio formats plus LPCM (8 channels) (HDMI to HDMI audio is “passed-through” from encoder to decoder) Additional restrictions may result from the audio supported at encoder’s input. Decoder DisplayPort Video Specifications DisplayPort ZyPer4K ✓...
  • Page 81 ZyPer4K DisplayPort ZyPer4K ✓ DisplayPort Supports all major VESA resolutions and variations Resolutions including full HDR* support: 640x480 (p/i) 720x576 (25Hz/50Hz)(p/i) 800x600 1024x768 1280x720 (p/i) 1280x1024 (p) 1366x768 1440x1080 (p) 1600x1200 (p) 1920x1080 (p/i) 2048x1536 (p) 3840x2160 (p) Including 4:4:4, 60 Hz support 4096x2160 (p) Including 4:4:4, 60 Hz support all at 24/25/29.97/30/50/59.94/60Hz refresh rates except where noted...

  • Page 82: Physical And Environmental

    ZyPer4K Physical and Environmental The following parameters apply to all encoders and decoders unless specifically stated otherwise. Type Parameter A/C Adapter 100-1240VAC 50-60Hz 0.7-0.45A draw on AC Mains Output Max: 12VDC 2.5A ZyPer4K unit power 12VDC at 1.2A max 12W nominal (Standard Fiber Encoder/Decoder) consumption 12VDC at 1.6A max 15W nominal (Standard Copper Encoder/Decoder) 12VDC at 1.2A max 12.5W nominal (Extended input Fiber Encoder)

  • Page 83: General Safety And Care Instructions

    ZyPer4K General Safety and Care Instructions Safety WARNING: When using electronic products, basic precautions should always be followed, including: • Keep these instructions. • Heed all warnings. • Follow all instructions. • Do not use this apparatus near water. • Clean only with in accordance with cleaning instructions included in this manual.
  • Page 84 Opening or damaging the ZyPer4K unit in any way voids the warranty and immediately nullifies any assertion of regulatory compliance made by ZeeVee. Any required service shall be performed by trained and qualified service personnel authorized by ZeeVee.

  • Page 85: Cleaning

    ZyPer4K Cleaning Encoder, Decoder and ZyPerMP Unit Cleaning Procedures Before cleaning: 1.Switch off or fully disconnect the AC power from the external supply unit connector to the ZyPer unit. 2.If the state of the AC power cannot be established, disconnect the DC input plug from the ZyPer unit before proceeding.

  • Page 86: Zypermp Specific Cleaning Procedure

    ZyPer4K 5. Air vents shall be checked to make sure that they are free of accumulated lint or blockages. Should the air vents appear clogged use a vacuum cleaner with a soft-bristle brush attachment to loosen and draw the debris out of the vents and away from the unit. Do not loosen and blow the debris in to the unit as internal buildup of debris will degrade the ability of the unit to cool itself and reliability may be adversely affected.

  • Page 87: Important Siting And Application Considerations

    ZyPer4K Important Siting and Application Considerations ZyPer4K Equipment Type and Uses ZyPer4K Intended Uses • Equipment is intended for the distribution of Audio Visual Information in and around a facility. • Equipment is intended to distribute Human Interface and control information over the same network as the Audio Visual information following the same or different logical distribution paths.

  • Page 88: Installation Environment

    ZyPer4K Installation Environment The general area where the ZyPer4K unit is to be installed shall be clean and free of obstructions or clutter. Mounting Options • Unit may be mounted horizontally on the installed rubber feet • Unit may be bolted to a horizontal surface using the provided L-brackets with or without feet installed.
  • Page 89 ZyPer4K The optional L-Brackets allow for the ZyPer4K unit to be rigidly mounted flat to a cart, plate, wall, or any type of flat surface. The hole, cross, and slot cutouts allow for great flexibility in mounting When using the L-Brackets, first remove the screws and rubber feet on the bottom of the unit. Retain the screws as they will be used to affix the L-Brackets to the ZyPer4K unit body.
  • Page 90 The installer must provide the appropriate hardware to mount the L-Brackets to whatever surface is used. Drywall: When mounting to drywall, ZeeVee recommends use of Drywall anchors for #6 up to #10 hardware and washers appropriate to the size screw utilized. The recommended sequence of hardware would be;...

  • Page 91: Vesa Mounting Bracket

    ZyPer4K VESA Mounting Bracket There is an optional VESA mounting bracket available from ZeeVee for mounting most unit styles to shelfs, walls or other sturdy surfaces as well as directly to VESA compatible displays. This VESA bracket is compatible with any standard size ZyPer4K encoder or decoder as well as Silent Decoder units.
  • Page 92 ZyPer4K Example mounting ZyPer4K to center of 200x200 VESA bracket using all 4 mounting holes/ screws. This would prevent the use of wall mounting bracket hardware. Example mounting ZyPerK to side of 200x200 VESA bracket using 2 mounting holes/screws. This may enable use of wall mounting bracket hardware. Rev: 20240717 Page User Manual...

  • Page 93: Ventilation

    ZyPer4K Ventilation Ambient environmental temperature and humidity shall not exceed that specified in the Detailed Specifications portion of this document. Ambient temperature in this case refers to the temperature of air entering the device through the ventilation grille. Care should be taken to not enclose the device or deploy in an fashion where airflow loops or local “hot spots”...

  • Page 94: Ac Mains Connection

    The overall system compliance is dependent on each of the provided elements being present and operational. INFORMATION: The introduction of a foreign, non-ZeeVee element nullifies any claim of regulatory compliance asserted by ZeeVee. The AC/DC power supply shall be powered from the appropriately rated AC mains voltage which allows for a wide range of input, generally from 100VAC through 240VAC.

  • Page 95: Ac Power Cord

    ZyPer4K AC Power Cord Connect the external AC/DC supply unit to the AC mains with a UL-listed detachable power cord, 3-wire, type SJ or equivalent, 18 AWG min., rated 250 V min., plug 5-15P configuration for 120V application, or 6-15P for 240V application. AC/DC converter inlet side of AC cord shall be of type IEC320C13 •...

  • Page 96: Equipotential Referencing

    ZyPer4K Equipotential Referencing Safety and compliance with standards is highly dependent on the proper crafting of the electrical realm in which electrical equipment operates. It is also good practice to properly ground all electrical equipment. The ZyPer4K equipment may be connected to the the known and common equipotential reference by bonding the devices electrically.
  • Page 97 High-quality wire of 16 gauge or heavier is recommended by ZeeVee, It is the responsibility of the installer to determine the needs of the specific installation. Rev: 20240717 Page...

  • Page 98: Responsibility And Stewardship

    It is the responsibility of our customers to determine that their use of ZeeVee products is safe, lawful, and technically suitable for their applications. Because of possible changes in the laws and regulations, we cannot guarantee that the status of the listed products will remain unchanged.

  • Page 99: Waste Electrical And Electronic Equipment

    It is the responsibility of our customers to determine that their use of ZeeVee products is safe, lawful, and technically suitable for their applications. Because of possible changes in the laws and regulations, we cannot guarantee that the status of the listed products will remain unchanged.

  • Page 100: Fcc Compliance Statement

    Use only approved and properly shielded cables of good quality. Address any inquiries to: ZeeVee, Inc. 295 Foster Street, Suite 200 Littleton, MA 01462 Rev: 20240717...

  • Page 101: Emc Information

    EMC characteristics. The supplied Power Supply (AC/DC Conversion unit) should be used. The ZeeVee 12V Rack Mount Power Supply (Z4KPWRCTR12) may also be used. Any other AC/DC supply has not been tested or verified to perform at the levels indicated in this manual.

  • Page 102: Electromagnetic Immunity

    ZyPer4K Electromagnetic Immunity Test EN60601 Compliance Level Result Deployment Note Standard Expect hard floor of wood, tile, ceramic, metallic material. If Electrostatic ± 6kV contact PASS floor has synthetic covering, 61000-4-2 Discharge (ESD) ± 8kV air expected relative of humidity of 30% shall be maintained to avoid static charge buildup.

  • Page 103: Physical Dimension Diagrams

    ZyPer4K Physical Dimension Diagrams ZyPer4K Standard Size Units
 Rev: 20240717 Page User Manual...
  • Page 104 ZyPer4K ZyPer4K Extended Size Units Rev: 20240717 Page User Manual...
  • Page 105 ZyPer4K ZyPer4K XS Units Rev: 20240717 Page User Manual...
  • Page 106 ZyPer4K ZyPer4K XS Units (Encoder with USB-C and Decoder with RS-232) Rev: 20240717 Page User Manual...
  • Page 107 ZyPer4K ZyPer4K XR Units
 Rev: 20240717 Page User Manual...
  • Page 108 ZyPer4K US Wallplate (Dimensions in millimeters) EU Wallplate (Dimensions in millimeters) Rev: 20240717 Page User Manual...

  • Page 109: Known Good Usb-C Cables

    ZyPer4K Appendix 1 Known Good USB-C Cables The following USB-C cables have been tested with the ZyPer4K Wallplate units for simultaneous support of the following features: 3840 x 2160 video at 60Hz. Audio. USB Data for Webcam video transfer. 60W power charging. (External power supply to ZyPer4K required) Manufacturer / Part Number Length Link...

  • Page 110: Usb-C Charging

    6. Video Data specs must be 20Gbps per lane (4K@60Hz) or above. (40Gbps cable) 7. USB Data specs must be 5Gbps (USB 3.0) 8. Must have built in E-Mark IC ZeeVee is not responsible for damage to any equipment caused by poor or incorrect USB-C cables.
 Rev: 20240717...

  • Page 111: Poe Power And Poe Switches

    It is important to remember that the ZyPer4K is a device that requires a 10Gb network. Therefore any PoE injector must also support 10Gb data transfer. ZeeVee recommends the following 10G PoE Injector for use with the ZyPer4K Wallplate and ZyPer4K-XS copper units.

  • Page 112: Why Shielded Ethernet Cable Is Required

    ZyPer4K Why Shielded Ethernet Cable Is Required Shielded cable must be used with PoE systems to provide the ZyPer4K-XS or XR endpoint a path to ground when another path is not available. Shielded cable options include: F/UTP, S/ UTP, F/FTP, S/FTP, SF/UTP and SF/FTP. Unshielded Example: Rev: 20240717 Page...
  • Page 113 ZyPer4K Shielded Example (F/UTP, S/UTP, F/FTP, S/FTP, SF/UTP or SF/FTP) Rev: 20240717 Page User Manual...

  • Page 114: Accessories

    ZyPer4K Appendix 4 Accessories Part Number Description Z4KSFP10G85-3M ZyPer4K, Fiber Optic Transceiver, SFP+ 10Gbps 850nm MMF 300m Z4KSFP10G31-10K ZyPer4K, Fiber Optic Transceiver, SFP+ 10Gbps 1310nm SMF 10km Z4KIRTX ZyPer4K Cable, IR Emitter, 10ft (Not for use with wallplate units) Z4KIRRX ZyPer4K Cable, IR Receiver, Dual band, 34-60KHz, 10ft (Not for use with wallplate units) Z4KRACKC1...
  • Page 115 HDMIEXT ZeeVee HDMI Extender is a 50M HDMI and IR Extender Pair. Transmitter and Receiver. UHD@60Hz HDR Support. Includes Transmitter, Receiver, InfraRed TX/RX and two International Power supplies. Requires power on both ends.

  • Page 116: Zyper4K Part Numbers

    ZyPer4K Appendix 5 ZyPer4K Part Numbers Part Number Description Z4KENCF3 ZyPer4K HDMI 2.0 input Encoder, with IP streaming via 10Gbit/fiber. Supports analog audio, IR, RS-232. No USB. Includes power supply. Requires ZyPer4K Decoder. Cables not included. Z4KENCF3U ZyPer4K HDMI 2.0 input Encoder, with IP streaming via 10Gbit/fiber. Supports USB, analog audio, IR, RS-232.
  • Page 117 ZyPer4K Part Number Description Z4KANLENCF3U ZyPer4K Extended Module, HDMI 2.0 and analog video (component, composite, VGA, S-video) input Encoder, with IP streaming via 10Gbit/fiber. Supports USB, analog audio, IR, RS-232. Includes power supply. Requires ZyPer4K Decoder. Cables not included. Z4KHDMIENCF3 ZyPer4K Extended Module, Dual HDMI 2.0 input Encoder with single HDMI loop-out, with IP streaming via 10Gbit/fiber.
  • Page 118 ZyPer4K Part Number Description Z4KENCC3 ZyPer4K HDMI 2.0 input Encoder, with IP streaming via 10Gbit/copper. Supports analog audio, IR, RS-232. No USB. Includes power supply. Requires ZyPer4K Decoder. Cables not included. Z4KENCC3U ZyPer4K HDMI 2.0 input Encoder, with IP streaming via 10Gbit/copper. Support USB, analog audio, IR, RS-232.
  • Page 119 ZyPer4K Part Number Description Z4KHDMIENCC3 ZyPer4K Extended Module, Dual HDMI 2.0 input Encoder with single HDMI loop-out, with IP streaming via 10Gbit/copper. Supports analog audio, IR, RS-232. Includes power supply. Requires ZyPer4K Decoder. Cables not included. Z4KHDMIENCC3U ZyPer4K Extended Module, Dual HDMI 2.0 input Encoder with single HDMI loop-out, with IP streaming via 10Gbit/copper.
  • Page 120 ZyPer4K Part Number Description Z4KENCC3XS-WPUS-I ZyPer4K-XS HDMI 2.0 and USB-C  input Wallplate Encoder (US Form factor), with IP streaming via 10Gbit/copper. PoE. Supports analog audio, IR, RS-232. Icron USB supported between ZyPer4K Classic devices.  Audio/Video compatible with any ZyPer4K Decoder. Power supply not included.

  • Page 121: Disclaimers

    ZeeVee hardware designs are property of ZeeVee. Components, sub-assemblies, and methods utilized in the designs are free of any encumbrances or appropriate licenses and rights have been obtained by ZeeVee for the use in the described products in the intended manner.

Table of Contents
