ZyPer4K
Device Technical Specifications
Encoder HDMI Video Specifications
All encoders have one exposed HDMI port.
HDMI
HDMI Standard Port
Direction
Connector
HDMI Resolutions
HDMI Audio
Z4K Quad Encoder
ZyPer4K
Enc
✓
HDMI 2.0 with HDR* and HDCP 2.2 Support
✓
Input
✓
Type-A receptacle (female)
✓
Supports all major VESA resolutions and variations
including full HDMI 2.0 and HDR* support:
640x480
720x576
800x600
1024x768
1280x720
1280x1024 (p)
1366x768
1440x1080 (p)
1600x1200 (p)
1920x1080 (p/i)
2048x1536 (p)
3840x2160 (p) Including 4:4:4, 60 Hz support
4096x2160 (p) Including 4:4:4, 60 Hz support
all at 24/25/29.97/30/50/59.94/60Hz refresh rates
except where noted
HDR fully supported in "Genlocked" mode
HDR inputs reduced to 8-bits on output in "Fast-Switch
mode"
✓
LPCM, Dolby (5.1, 6.1, 7.1), AC3, DTS, Dolby EX,
THX, DTS-ES, Dolby TrueHD, DTS-HD Master
(HDMI to HDMI audio is "passed-through" from
encoder to decoder)
Additional restrictions may result from the audio
supported at encoder's input.
Page
(p/i)
(25Hz/50Hz)(p/i)
(p)
(p)
(p/i)
(p)
8
of
11
