© 09/2014 ALL RIGHTS RESERVED. Technical changes possible. No liability for misprints.
9.
Place facia plate
Reinstall everything in
reverse order to finish
installation
• Subaru Outback 2015->
Compatible with these double DIN devices
Double DIN navigation
3
4
3
All installation work must be performed by a qualified professional installer only.
The manufacturer / dealer is not liable for any kind of incidential or indirect damages.
Installation Manual
Double DIN Kit
piano black:
381296-07-1
Double DIN Kit contents
1
(1) facia plate
(2) mounting bracket right
(3) mounting bracket left
(4) cross recessed pan head screw
4
2
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ACV 381296-07-1
Summary of Contents for ACV 381296-07-1
- Page 1 Installation Manual Double DIN Kit Place facia plate piano black: 381296-07-1 Reinstall everything in reverse order to finish • Subaru Outback 2015-> installation Compatible with these double DIN devices Double DIN navigation Double DIN Kit contents (1) facia plate (2) mounting bracket right...
- Page 2 Remove panel of air condition Remove all screws control unit of OEM head unit Remove screws of air condition Remove OEM head unit control unit Remove cables carefully Mount mounting brackets on double DIN head unit Remove air condition control unit Unclip air vents Connect all required circuit Disconnect hazard switch...
