8a. 1-DIN Radio install
(only 281275-15-1 / 281275-15-2)
Attach mounting frames and
pocket to facia plate and
1-DIN radio
10. Connect all cables
Place 2-DIN head unit onto
dash board
Fix 2-DIN head unit using
the original screws
11. Reinstall everything in
reverse order to finish
installation
• SsangYong Tivoli 06/2015->
Compatible with these double DIN devices
Double DIN Navigation
4
3
Double DIN Set contents
• (1) Facia Plate
• (2) Mounting Bracket Right
• (3) Mounting Bracket Left
• (4) flat headed screw
Installation Manual
Double DIN Kit
colour
2-DIN
2-DIN with pocket
anthracite
381275-15-1
281275-15-1
piano-black
381275-15-2
281275-15-2
1
pocket (only 281275-15-1 / 281275-15-2)
4
2
Advertisement
Table of Contents
Related Manuals for ACV 381275-15-1
Summary of Contents for ACV 381275-15-1
- Page 1 Installation Manual 8a. 1-DIN Radio install Double DIN Kit (only 281275-15-1 / 281275-15-2) colour 2-DIN 2-DIN with pocket anthracite 381275-15-1 281275-15-1 piano-black 381275-15-2 281275-15-2 Attach mounting frames and pocket to facia plate and • SsangYong Tivoli 06/2015-> 1-DIN radio Compatible with these double DIN devices Double DIN Navigation 10.
