PLEASE READ THIS ENTIRE OWNER'S MANUAL BEFORE YOU INSTALL AND USE YOUR
NEW BARI WOOD STOVE.
To reduce the risk of fire, follow the installation instructions. Failure to follow these
instructions can result in property damage, bodily injury, or even death.
CONTACT LOCAL AUTHORITIES WITH JURISDICTION (BUILDING DEPARTMENT or FIRE
OFFICIALS), ABOUT PERMITS REQUIRED, RESTRICTIONS AND INSTALLATION
OWNER'S MANUAL
OPERATING INSTRUCTIONS
We recommend that our products be installed
and serviced by professionals who are
certified in the U.S. by NFI (National Fireplace
Institute), or by W.E.T.T. (Wood Energy
Technology Transfer) in Canada.
SAVE THIS OWNER'S MANUAL
INSPECTION IN YOUR AREA.
California Prop 65
chemicals including glass wool fiber and carbon
monoxide which are known to the State of California to
cause cancer, birth defects or other reproductive harm.
For more information go to www.P65Warnings.ca.gov
(Bari Model 8171)
(Bari Plus Model 8172)
Wood Stove
INSTALLATION AND
www.nficertified.org
www.wettinc.ca
PFS Report F20-618
FOR FUTURE REFERENCE
WARNING: This product can expose you to
Hase Bari Wood Model 8171 & 8172
Manual: 6400-41418
R: 11/3/2020
