R e m o v e r e f l e c t o r

Tools Required:

•

W A R N I N G :

Step 1:

Step 2:

Step 3:

Step 4:

Reflector Housing Assembly

minimally padded work surface (cardboard, carpet, or rubber mat recommended)

This procedure may crack or break the reflector. Always wear gloves, safety

glasses, and a dust mask when performing this procedure.

Place the reflector housing face down on your work surface so that the concave

reflector surface points downward.

Loosen the clutch and rotate the yoke so that it is perpendicular to the housing

at roughly a 90° angle. Tighten the clutch.

Using the yoke as your handle, raise the housing assembly off of the work

surface a few inches and then firmly tap the housing on the work surface. This

should force the reflector out of its clips.

Carefully lift the housing to see if the reflector is released. If it is not, repeat step

3 with slightly more force.
