19°, 26°, 36°, And 50° Lens Tubes - ETC Source Four Assembly Manual

19°, 26°, 36°, and 50° Lens Tubes
3
8A
1
13
10
Figure 14
Reference
Number
1
2
3
4
5
6
7
8
8A
9
10
11
12
13
14
15
16
17
18
19
12
11
9
12
Part
Number
7060A3137
7060A3139
7060A4009
7060A4012
7060A4002
7060A4001
7060A4004
7060A4020
7060A4021
7060A3079
HW750
HW369
HW370
HW534
7060A4008-01
HW5143
7060A4033
7060A4034
7060A4035
7060A4036
2
5
6
7
8
4
Note: Lenses are degree
specific. Do not interchange
lenses (i.e. do not place a
19° lens in a 26° slot).
Description
Lens tube, left, painted
Lens tube, right, painted
Bushing, guide
Pad lens support - asphere
Pad lens support - meniscus set
Aspheric lens, 19°
Aspheric lens, 26°
Aspheric lens, 50°
Meniscus lens, 36° set, front
Bi-convex lens, 36° set, rear (36° Only)
Clip, gel retainer, 90° bend
Spring, retainer
Screw, PHMS, 8-32 x 3/4, black zinc
Nut, Ny-Lok, 8/32, black zinc
Nut, hex, 1/4-20, black zinc
Knob set with male insert
Washer, flat, 1/4
19° lens tube label
26° lens tube label
36° lens tube label
50° lens tube label
Place side of lens
with paint dot
toward front of
16, 17, 18, 19
lens tube.
19 ° (6x16)
Red dot
14
15
26 ° (6x12)
Black dot
36 ° (6x9)
No dot
50 ° (4.5x6)
Yellow dot
Source Four Assembly Guide
Quantity
Required
1
1
8
5
10
1
1
1
1
1
1
1
4
3
2
1
1
1
1
1
1
