Introduction
This manual is intended to guide ETC Service Technicians through the process of upgrading existing
Sensor enclosure installations to Sensor3 enclosures with a CEM3 control module. This manual covers SR
or HSR 6, 12, 24, and 48 enclosures.

Overview of this Manual

Preparation (page 5)
•
Remove the Old CEM (page 6)
•
Data Terminations (page 8)
•
Attach new power harness (page 10)
•
backplane
Install the New Backplane (page 13)
•
Transfer Panic Wiring (if present) (page 14)
•
install the new ones
Change out the AF Cards (if present) (page 14)
•
• Verify the Retrofit (page 16)
Configure the CEM3 (page 16)
•

Document Conventions

These symbols are used to alert you to danger or important information:
Note:
CAUTION:
WARNING:
WARNING:
Safety
Please note the following safety warnings before use:
• Disconnect power from the enclosures before all maintenance.
WARNING:
Introduction
: Before you open the enclosure
: Label and remove the existing equipment
: Adapt and connect the data terminations
: Put the dimmers back in the enclosure and power up the enclosure
: Program a configuration for the CEM3
Notes are helpful hints and information that is supplemental to the main text.
A Caution statement indicates situations where there may be undefined or
unwanted consequences of an action, potential for data loss or an equipment
problem.
A Warning statement indicates situations where damage may occur, people
may be harmed, or there are serious or dangerous consequences of an action.
RISK OF ELECTRIC SHOCK! This warning statement indicates situations where
there is a risk of electric shock.
RISK OF ELECTRIC SHOCK! Enclosures without an accessible power disconnect
device cannot be serviced safely. Before removing dimmer or control modules
for service, de-energize main feed to dimmer enclosure and follow
appropriate Lockout/Tagout procedures as described in NFPA Standard 70E.
It is important to note that electrical equipment such as enclosures can
present an arc flash safety hazard if improperly serviced. This is due to
available large short circuit currents on the feeders of the equipment. Any
work on energized equipment must comply with OSHA Electrical Safe
Working Practices.
: Adapt and connect the power harness for the new
: Transfer the wiring and install new components
: Remove the existing Advanced Feature cards and
: Replace the beacon PCB with the new one
