6:
Using the permanent marker, mark "A" on both ends of the DMX connector.
7:
Disconnect the DMXB wires terminal 3, 9, and 10 of the J2 connector.
8:
Connect the DMXB wires to another 8-pin connector using a precision 3/32" (2.5 mm) flat-blade
screwdriver. DMXB wires connect to the following terminals:
• J2-3 = DMXB-1 (DMXB common)
• J2-9 = DMXB-2 (DMX-)
• J2-10 = DMXB-3 = (DMX+).
9:
Using a permanent marker, mark "B" on both ends of the DMX connector.
Cap ETCLink Wires (if present)
10:
If your enclosure has an ETCLink connection, disconnect the link wires from terminals #11–14 of
the J2 connector.
11:
Secure wires as follows:
a: Cut all bare ends from the link wires.
b: Cap the wire ends with 3/16" (5 mm) heat shrink (fold back or pinch end of heat shrink while
still warm to seal end).
c: Coil the wires into a neat bundle and secure with a zip tie.
d: Secure the cabling out of the way of the enclosure with tie mounts and zip ties as needed so
it does not interfere with normal enclosure function
Note:
12:
Finish removing the old backplane metalwork. Discard the old backplane.
The Retrofit
Wire runs for ETCLink are abandoned in the enclosure and can be used in the future
as DMX wire runs in the event that a DMX line must be replaced for any reason.
.
9
