C-Series Off-Highway
Installation Manual

4. Space requirements - conditions, design

4.1 Sensor dimensions

Sensor
36.1
Sensor assembled with pressure pipe E2
36.1
Controlling design dimensions are in millimeters
Fig. 3: Temposonics
C-Series Off-Highway sensor
®
Null zone
16.7
Position magnet 401842
9
Null zone
16.7
Position magnet 401842
9
7
Stroke length
72...275
Stroke length
72...275
I 6 I
Dead zone
22.7
Dead zone
33
