Copying Protocols Between UDM-0102s

Once protocols have been learned by the Hub through the Web Browser, they will
remain on the Hub. AMX recommends the Web Browser be used at all times to
allocate protocols to UDM-0102s.
1. Once an IR protocol has been learned for a specific port it can simply be copied across to other ports
using the TFTP application and the network port.
2. First, you must retrieve the IR file from the UDM-0102. IR files all start with an I and use a file
extension to indicate number. These could therefore take the form isonymode1.001, IRtable.001 etc.
3. At the command prompt use the following command.
tftp –I [IP address of hub] GET irtable.001
Where irtable is the user defined name given to the IR code on port 1 and where the .001 file
extension relates to the port number.
The same command structure and method is used to copy and paste serial
commands between ports. In this instance the filename will begin with the letter S.
The IR protocol can be loaded to an UDM-RX02 by using the following command at the hub:
tftp –I [IP address of hub] GET irtable.hub
and the following command at the receiver:
tftp –I [IP address of hub] PUT irtable.hub

Upgrading Input Controllers

1. Run the TFTP client.
2. Start a command session on the PC. Change to the directory where the .ROM files are stored on the
PC e.g. cd\hub.
3. Type in the following command at the prompt observing the parameters below;
tftp –i [IP address] PUT uXXXXXXX.022
