You can then select the Extruder
heating process.
• Once the extruder reaches the target temperature of your filament you can start printing.
If you want to print with material with other temperature properties, select USER1 or USER2, then click the icon
to adjust the temperature using the arrows.

5.2. Loading the filament

• Heat up the printer.
• Take the end of the filament out of the securing hole on the Filament spool.
•
Cut and the end of the filament so the filament is straight and has no damages
bends kinks or melted parts.
• Remove the filament guide tube from the insert hole on the top of the extruder.
• Insert the end of the filament from the spool through the FMS into the filament
guide tube. Until it comes out of the guide tube at the extruder.
• Set the switch on the top of the extruder to the left to the "open" position. Then
push the filament into the top of extruder hole.
•
When you see the nozzle printhead begin to eject the molten filament, reset
the extruder switch to the right "closed" position.
• Now reinsert the end of the filament guide tube into the hole at the top of the
extruder.
OPEN
icon, and the Bed icon (line with 3 wavy lines above) to start the
CLOSE
