Loading The Filament; Extrude Menu; Extrude - CraftBot CB4 FLOW Series User Manual

7.2.

Loading the filament

• Heat up the printer.
• Take the end of the filament out of the securing hole on the Filament spool.
• Cut and the end of the filament so the filament is straight and has no damages
bends kinks or melted parts.
• Remove the filament guide tube from the insert hole on the top of the extruder.
• Insert the end of the filament from the spool UP into the filament guide tube
holder, then into the filament guide tube. Until it comes out of the guide tube at
the extruder end.
• Push the filament into the top of extruder hole.
7.3.

Extrude menu

7.3.1. Extrude

Select the Extrude menu
• Before extruding, make sure the head is near the build plate, not
pressed into the plate or directly above.
• To print filaments from the print head, use the down arrow
the touch screen. Press and hold the button to keep the filament
pressed out of the head.
• Automatic filament feed can also be performed by pressing the
Load button
once, the head automatically extrude some filaments.
• Filament loading is successful when the melted filament flows out
of nozzle evenly and vertically.
• Watch out! The freshly spilled molten filament is hot. Avoid contact
on the Home screen.
on the bottom bar. By pressing the button
on
19
