Unpacking the Connection Kit

When receiving and unpacking the Kit, check it for damage in transit. Report
any damage to the forwarding agent or responsible party. Dispose of the
packaging material in an environmentally friendly manner.

Scope of delivery

The following items are included in the scope of delivery:
Quantity
1
2
6
1
1
1
1
1
2
1
2
1
2
1
2
6
1
TAK
MoWa TAK 4406591 en-us 2018-08-13.docx
Part number 3039235
Pan head screw M5x120
Suction tube Ø 26.9 x 2.3, length 800 mm with G3/4" thread on
one side, 200 mm on the free end angled 90°
Straight screw-in union GE 22L, G3/4"
Hose assembly DIN 20066, DN 20, 1 SN, length 1250 mm
Elbow fitting 90° DIN 3942, 22L
Straight screw-in union GE 22L, G1/2"
Straight screw-in union GE 15L, G1/2"
Hose assembly DIN 20066, DN 12, 1 SN, length 1250 mm
Elbow fitting 90° ISO 8434, 15L
Part number 3042278
Pan head screw M5x120
en(us)
Unpacking the Connection Kit
Designation
Manifold block
Seal for breather filter
Setscrew M5x8
Return tube Ø 38 x 3
Manifold block
Seal for breather filter
Setscrew M5x8
