2. Apply adhesive to the thread of
the suction tube.
Screw the tube into the adapter.

Adapter and breather filters

Note that the circuit diagram of the breather filter must be executed in
accordance with DIN 24557/T2.
1. Removing the mounted
breather filter
2. Remove the existing seal
between the breather filter and
the tank.
Clean the sealing faces.
Mount a new seal.
TAK
