3.
Fasten the seal and the adapter
on the tank with the M5 x 120
cheese head screws suppled.
4.
Screw the screwed fittings into
the adapter.
Connect the R and S
connections of the adapter and
bypass-flow filter unit. Use the
hose lines provided for this
purpose.
TAK
MoWa TAK 4406591 en-us 2018-08-13.docx
en(us)
Assembling the Kit
Page 11 / 16
2018-08-13
