- Page 1 OLF-5-TAK Tank Connection Kit Installation and Maintenance Instructions English (translation of original instructions) Keep for future reference. Document No.: 4406591...
-
Page 2: Imprint
+49 6897 509 1394 E-mail: guenter.harge@hydac.com © HYDAC FILTER SYSTEMS GMBH All rights reserved. No part of this work may be reproduced in any form (print, photocopy or by other means) or processed, duplicated or distributed using electronic systems without the written consent of the publisher. -
Page 3: Table Of Contents
Content Content Imprint ......................2 Documentation Representative ..............2 Content ......................3 Preface ......................4 Technical Support ..................4 Modifications to the Product ................ 4 Warranty ...................... 4 Using the documentation ................5 Unpacking the Connection Kit ..............6 Scope of delivery ..................6 Product Description .................. -
Page 4: Preface
Warranty For the warranty provided by us, please refer to the terms of delivery of HYDAC FILTER SYSTEMS GMBH. You will find these under www.hydac.com -> Legal information. Page 4 / 16 en(us) MoWa TAK 4406591 en-us 2018-08-13.docx... -
Page 5: Using The Documentation
Preface Using the documentation Note that the method described for locating specific information does not release you from your responsibility of carefully reading these instructions prior to starting the unit up for the first time and at regular intervals in the future. What do I want to know? I determine which topic I am looking for. -
Page 6: Unpacking The Connection Kit
Unpacking the Connection Kit Unpacking the Connection Kit When receiving and unpacking the Kit, check it for damage in transit. Report any damage to the forwarding agent or responsible party. Dispose of the packaging material in an environmentally friendly manner. Scope of delivery The following items are included in the scope of delivery: Quantity... -
Page 7: Product Description
Product Description Product Description The OLF-5-TAK Tank Connection Kit 2.0 is used for rapid retrofitting of bypass-flow filter units in hydraulic systems. The Kit can be integrated in all systems equipped with a breather filter for which the circuit diagram is executed in accordance with DIN 24557/T2. -
Page 8: Dimensions Of The Connector Threads
Product Description Dimensions of the connector threads Suction port S G3/4“ Return port R G1/2“ Suction tube G3/4“ Hydraulic data Viscosity Suction Return pressure Flow rate [l/min] [mm²/s] pressure [bar] [bar] -0.3 -0.1 -0.06 -0.06 -0.2 -0.18 The tabular values have been determined with the screw connections and flexible lines included in the scope of delivery. -
Page 9: Assembling The Kit
Assembling the Kit Assembling the Kit The assembly of the TAK is described in the following chapter for part number 3039235. This contains the part number 3042278. Suction and return tube Please note the following basic principles for the positioning of the lines in the tank: It is imperative that the end of the return tube be positioned below the oil level. -
Page 10: Adapter And Breather Filters
Assembling the Kit Apply adhesive to the thread of the suction tube. Screw the tube into the adapter. Adapter and breather filters Note that the circuit diagram of the breather filter must be executed in accordance with DIN 24557/T2. Removing the mounted breather filter Remove the existing seal between the breather filter and... - Page 11 Assembling the Kit Fasten the seal and the adapter on the tank with the M5 x 120 cheese head screws suppled. Screw the screwed fittings into the adapter. Connect the R and S connections of the adapter and bypass-flow filter unit. Use the hose lines provided for this purpose.
- Page 12 Use a new seal to mount the breather filter on the adapter. Use the available fastening screws for this purpose. Insert the filter and cover of the breather filter. The OLF-5-TAK can now be used. Page 12 / 16 en(us) MoWa TAK 4406591 en-us 2018-08-13.docx 2018-08-13...
-
Page 13: Kit Disposal
After dismantling the Kit and separating its various materials, dispose of it in an environmentally friendly manner. Contact / Service For product information or technical support or if you have comments or suggestions concerning this manual, please contact: HYDAC FILTER SYSTEMS GMBH Phone: +49 6897 509 1174 Fax: +49 6897 509 9046 E-mail: filtersystems@hydac.com... - Page 16 HYDAC FILTER SYSTEMS GMBH Industriegebiet Postfach 1251 66280 Sulzbach/Saar 66273 Sulzbach/Saar Germany Germany Tel: +49 (0) 6897 509 01 Central Fax: +49 (0) 6897 509 9046 Technical Department Fax: +49 (0) 6897 509 577 Sales Internet: www.hydac.com E-Mail: filtersystems@hydac.com...
