Physical Description

Reviewing the Rear Panel Design

shows the 3rd Gen Total Access 900 Series' rear panel layouts.
Figure 2

Rear Panel Interfaces

VOICE Connection
A single 50-pin female amphenol connector, labeled
for the analog FXS and FXO circuits (FXO is available as an option only on the Total Access
924). See Table A-1 on page 32
The Total Access 908 only uses circuits 1 through 8. The Total Access 916 only
uses circuits 1 through 16. The Total Access 924 uses circuits 1 through 24, and
the FXO interfaces are on circuits 17 through 24.
DSX-1 Interface
The
DSX-1 T1 0/2
the DSX-1 network interface pinouts.
Network Interface
The interface is a DS1 RJ-48C pin connection. See
NET T1 0/1
network interface pinouts.
10/100/1000Base-T Ethernet Interface and Activity LEDs
The Ethernet port (
when data traffic is being sent or received on the Ethernet port. The green link LED is on
14
Total Access 908
Total Access 916/924

Figure 2. Total Access 900 Series Rear Panel Layouts

for VOICE connector pin assignments.
interface is a DSX-1 RJ-48C pin connection. See
) is an RJ-45 connector with LEDs. The amber activity LED flashes
ETH 0/1
Copyright © 2020 ADTRAN, Inc.
TA 900 Series (3rd Gen) HIG
ETH
ETH
, provides the interconnect wiring
VOICE
Table A-2 on page 33
Table A-3 on page 33
for
for the T1
61213908F1-34A
