Configuring the
Total Access 900 Series
Web-Based GUI, AOS CLI,
and Connecting to the Unit
Quick Configuration Guide
The configuration parameters used in the example outlined in this document are for
instructional purposes only. Please replace all example entries with your specific parameters
to configure your application.

Using the Web-Based GUI

Web-Based GUI
The Web-based GUI is an online configuration tool that allows you to easily configure and view
the main settings, as well as the status of your system.
1. Connect the Total Access 900 Series unit to your network using the ETH 0/1 port on the rear
panel of the unit. The Total Access 900 Series units support auto MDI-MDIX crossover;
therefore, a straight-through cable can be used for this connection.
2. Configure your PC to obtain an IP address automatically (DCHP), or change the IP address
of your PC to 10.10.10.2. The default address for the Total Access 900 Series unit is
10.10.10.1.
Contact your network administrator if you need assistance changing your computer's
IP settings.
If you cannot change the PC's IP address, you will need to change the Total Access
900 Series IP address. For this procedure, see Connecting to the Total Access
900 Series on page 4.
3. Enter the IP address 10.10.10.1 (default) in your Internet browser Address field (see
example, below).
61210916L1-42.1B
Technical Support 1-888-4ADTRAN (1-888-423-8726)
March 2006
