Configuring the
Total Access 900 Series
DSX-1 Interface
Quick Configuration Guide
Please note that these examples are given for your study and consideration only.
They are to help you reach a better understanding of the fundamental concepts
before configuring your application. It will be necessary for you to modify these
examples to match your network configuration. Please replace all underlined entries
(example) with your specific parameters.
Please refer to the ADTRAN Operating System (AOS) Command Reference
Guide on your ADTRAN OS Documentation CD for detailed information on
individual commands and subcommands pertaining to the Total Access 900 Series
products.
DSX-1 Interface
The DSX-1 interface is located on the rear of the Total Access 900 Series products. It is labeled
DSX-1 T1 0/1 on the ADSL units and DSX-1 T1 0/2 on all other units. The DSX-1 interface allows
DS0s to be provided to customer's voice terminating equipment such as a PBX.
Configuring the DSX-1 Interface
The following steps demonstrate configuring the DSX-1 connection. In the following steps,
please substitute 1 (ADSL units) or 2 (all other units) for x in t1 0/x.
1. Start a VT100 terminal session to connect to your unit. If you need assistance, follow the
steps in the Total Access 900 Series Quick Configuration Guide (P/N 61210916L1-42.1).
2. Enter enable at the initial command prompt to access the Enable mode's priviledged
commands.
3. Enter configure terminal to access the Global Configuration mode.
4. At the (config)# prompt, enter interface t1 0/x to access the interface configuration mode for
the DSX-1 interface.
5. Enter description 12 Network to PBX to provide a text description of the channels provided
to the DSX-1 interface.
6. Enter tdm-group 2 timeslots 1-12 to create a TDM group of timeslots 1 through 12 on the
DSX-1 interface (t1 0/x).
7. Enter no shutdown to activate the interface.
8. Enter exit to return to the Global Configuration mode.
61210916L1-42.4B
Technical Support 1-888-4ADTRAN (1-888-423-8726)
March 2006
