Add the Sensor

1. Upon initial startup, the following message will be displayed: 'Sensor not yet installed.
Please install a sensor to take measurements'. This message will remain until you
proceed to the Install/ Configure command in the Sensor menu and install a new sensor.
2. The Sensor Manager appears first:
3. Select Add Sensor to install a new sensor. The Setup Sensor screen allows selection of
the instrument model and the communications port. Select Next when ready.
4. Place the desired port plate at the reflectance port and snap it into place.
10
LabScan XE Supplemental Manual for EasyMatch QC
Figure 8. Request 30-day Trial
Figure 9. Sensor Manager
Figure 10. Setup Sensor
