Key Features
1
ON/OFF switch
2
Reset button
3
PIC32MZ MCU
4
mikroBUS
sockets 1 and 2
™
5
Pushbuttons
6
Additional LEDs
7
Indication LEDs
8
Micro USB connector
9
32.768 KHz Crystal
10
Battery connector
11
mikroProg connector
12
LTC3568 USB power manager IC
13
24MHz Crystal Oscillator
