7. Technical data

Construction details:
Speed options:
Drive unit:
Bearing:
Platter:
Speed accuracy measured): +/- 0.05%
Power consumption:
Max. consumption:
Consumption in operation:
Off mode:
Total weight:
Dimensions (w x d x h):
Manufacturer warranty:
* Provided that the warranty card is correctly completed and returned to Clearaudio, or your product is registered
online at https://clearaudio.de/en/service/registration.php, within 14 days of purchase.
Page 16
• Resonance-optimised chassis shape
• Made of laminated wood and aluminium with precision CNC
machined surface
• All turntable feet are fine adjustable
• Optical Speed Control (OSC)
• Playback of one tonearm possible
• IMS – „Innovative Motor Suspension"
(Suspension design of the motor using 18 O-rings)
Comfortable speed change, 33 1/3rpm, 45rpm, 78rpm
• High torque 24V DC motor with belt drive
• Fully automatic self-calibration of the speed by a push of a
button
• Hybrid engine control:
A high resolution 12 bit digital-to-analog converter (DAC)
generates a motor reference voltage, which is fed into the
purely analog motor control.
Automatic compensation of friction and temperature changes
on the platter bearings and belts.
The speed remains in the perfect range at all times.
Clearaudio CMB ceramic magnetic bearing in main platter /
upper drive platter assembly.
Inverted bearing in lower drive platter.
50mm / 1.97 inch main platter, made out of synthetic material
with high density and excellent dimension.
15mm / 0.59 inch stability, precision CNC machined surface, solid
stainless steel sub-platter, dynamically balance.
5.0 watts
2.1 watts
1.8 watts
approx. 22kg (without tonearm and power supply)
approx. 495 x 343 x 160mm
approx. 19.49 x 13.50 x 6.30 inch
(without tonarm base, without tonearm)
2 years*
© clearaudio electronic GmbH, 2021-04
