I nnovation Basic

User manual

I nnovation Basic Wood

Package w ith Clearaudio

tonearm „Magnify" and

Clearaudio cartridge

I nnovation Basic Black

Picture: Package w ith

Clearaudio tonearm „TT5"

and Clearaudio cartridge

„Charisma V2 MM".

Picture:

„essence mc".

Made in Germany

Table of Contents

Need help?

Do you have a question about the I nnovation Basic and is the answer not in the manual?

Questions and answers

Summary of Contents for Clearaudio I nnovation Basic

Page 1 I nnovation Basic Black Picture: Package w ith Clearaudio tonearm „TT5“ and Clearaudio cartridge „Charisma V2 MM“. I nnovation Basic Wood Picture: Package w ith Clearaudio tonearm „Magnify“ and Clearaudio cartridge „essence mc“. © clearaudio electronic GmbH, 2018/ 05 Made in Germany...
Page 2 EQUI PMENT MAI NS WORKI NG SETTI NG Your Clearaudio product has been prepared to comply with the household power and safety requirements that exist in your area. This product can be connected to 230 V or 110 V AC (50 Hz and 60 Hz).
Page 3: Table Of Contents
User manual Contents 1. Packing overview ..........4 2. List of components ..........5 - 6 3. I nstallation and setup ......... 7 - 10 4. Fine adjustment of the motor ......11 5. Special instructions ..........12 6. Technical data ............. 13 Warranty information ..........
Page 4: Packing Overview
Card, Stroboscope Testrecord Innovation Basic turntable chassis incl. mounted lower bearing part and inte- grated motor unit; optional: tonearm Platter with integ- rated bearing upper part; power supply; optional: cartridge Pic. 1: Packing overview © clearaudio electronic GmbH, 2018/ 05...
Page 5: List Of Components
User manual 2. List of components Innovation Basic Clearaudio has developed a special and secure packing for your turntable that ensures a safe transportation. Please keep this original packing, if you need to ship the turntable. Below you find the part list of the Clearaudio...
Page 6 Screw driver Not shown: User Manual I MPORTANT NOTI CE: Please double check the tightness of all bolts, hardware, and mounting pods, as temperature fluctuations during transit may have caused the hardware to become loose. © clearaudio electronic GmbH, 2018/ 05...
Page 7: I Nstallation And Setup
User manual 3. I nstallation and setup Innovation Basic The setup of the turntable is easy as the turntable chassis is pre-assembled and has been tested at the factory. Please use the white gloves enclosed in order to avoid scratches or unwanted fingerprints (platter). turntable requires a space for setup of at least 18.90 inch x 19.29 inch.
Page 8 Remove the cap from the ceramic shaft of the bearing and pt 1-2 drop of the supplied synthetic bearing oil on the caramic shaft (Art. No. AC068, also available through www.analogshop.de). Pic. 6: Using the bearing oil © clearaudio electronic GmbH, 2018/ 05...
Page 9 User manual In the next step remove the lamination of the sensor, mounted on the turntable chassis (picture 7: red frame). Please remove the lamination extreme carefully and avoid any soiling and scratches. Pic. 7: Removing the lamination 6.1) Take the platter with both hands (with white gloves) carefully out of the packing. Please pay attention that the integrated bearing does not fall out of the platter! The flat side of the platter should face to the chassis and the side with the cut-out (for the record) should face up.
Page 10 33 1/ 3 rpm is reached. After the initial setup we recommend to let the turntable spin for at least 15 to 30 minutes. This ensures a smoother break in. Pic. 11: Connection of power supply and motor © clearaudio electronic GmbH, 2018/ 05...
Page 11: Fine Adjustment Of The Motor
Clean the sensor and the scale ring with a little isopropyl alcohol and a cotton bud. Be careful and avoid any scratches on the sensor or the scale ring! If the motor has further more speed variations please contact your nearest authorized Clearaudio dealer or directly the Clearaudio factory (address on page 13).
Page 12: Special Instructions
• To avoid any dust coming into the bearing, the bearing hole needs to be covered as well. Only if the product is returned in its original packing Clearaudio can provide the warranty. 5.3 Service In case of any necessary, service for all Clearaudio products should be done by authorized perso- nal only. Innovation Basic...
Page 13: Technical Data
Warranty: 5 years* (see page 14) * Provided that the warranty card is correctly completed and returned to Clearaudio within 14 days of purchase. Clearaudio electronic is not responsible for typographical errors in descriptions. Technical specifications subject to change or improvement without prior notice.
Page 14: Warranty Information
Le reçu ou la facture constituent des preuves suffisantes. DEUTSCH GARANTI E Bei Garantiefragen wenden Sie sich bitte zunächst an Ihren Clearaudio Händler. Heben Sie Ihren Kaufbeleg gut auf. WICHTIG! Die Angaben auf Ihrer Quittung erlauben uns die Identifizierung Ihres Gerätes und belegen mit dem Kaufdatum die Dauer Ihrer Garantie-Ansprüche.
Page 15 ESPAÑOL GARANTI A Para obtener información acerca de la garantia póngase en contacto con su distribuidor Clearaudio. GUARDE SU RECI BO DE COMPRA Su recibo de compra es su prueba permanente de haber adquirido un aparato de valor, Este recibo deberá...
Page 16 Stroboscope Testrecord Please place the on your turntable platter and start the engine of your Stroboscope Testrecord turntable. The big advantage of the Clearaudio is, that you can place your Stroboscope Testrecord cartridge onto the , while measuring the speed, as there are grooves provi- ded on the disc.
Page 17 With the outside scale you can detect the speed of 33 Hz and with the inside scale you can detect Stroboscope Testrecord the speed of 45 Hz. Again, the big advantage of the Clearaudio is, that you can place your cartridge onto the stroberecord, while measuring the speed, as there are grooves provided on the disc.
Page 19 User manual Made in Germany...
Page 20 Phone/ Tel.: + 49 9131 40300 100 Fax: + 49 9131 40300 119 www.clearaudio.de www.analogshop.de info@clearaudio.de Handmade in Germany (Technische Änderungen vorbehalten - Technical specification are subject to change without prior notification) 2018 © clearaudio electronic GmbH, 2018/ 05 Made in Germany...
