Summary of Contents for Clearaudio Master Jubilee
- Page 1 Master Jubilee User manual Pic. similar © clearaudio electronic GmbH, 2024-04 Made in Germany...
- Page 2 Germany by Clearaudio Electronic GmbH. Just in time for its 45th anniversary, Clearaudio takes the Reference Jubilee turntable to a new level by doubling the size of the turntable chassis. The new raised design, as well as the outsourced motor unit, now provide the possibility of mounting a second tonearm.
- Page 3 5. Maintenance Never use agressive cleaning detergent. Do not use dry cloths for cleaning as this generates static electricity. Suitable cleaning and care products from Clearaudio are available from www.analogshop.de or from specialist retailers. The bearing of the turntable platter can be lubricated every 2 years with the oil provided.
- Page 4 Otherwise serious damage can occur. Remove also the pulley from the motor axle to avoid any damage during transport. Clearaudio assumes no liability for any damage that may occur due to incorrect packing. 9. Disposal Do not dispose this product together with other waste.
-
Page 5: Table Of Contents
User manual Content 1. Package contents overview ..........6 - 7 2. List of components ...............8 - 9 3. Set-up ..................10 - 17 4. Mounting of tonearm and cartridge ........18 5. Initial operation and calibration of the speed .....19 - 20 6. -
Page 6: Package Contents Overview
User manual 1. Package contents overview Clearaudio has developed a secure packing for your Master Jubilee turntable to ensures safe transportation. Please keep this original packing, if you need to ship the turntable in the future. Box 1 of 2... - Page 7 User manual Box 2 of 2 Master Jubilee turntable, Accessories, user manual, warranty card, Clearaudio quality card, Stroboscope Testrecord Pic. 1.1: Package contents overview Made in Germany Page 7...
-
Page 8: List Of Components
User manual 2. List of components Please use the list below to check all components of your newly purchased Clearaudio Master Jubilee turntable. Pic. 2: List of components Turntable chassis incl. lower 6x Flat Pads bearing part Stainless steel sub-platter... - Page 9 (depending on the tonearm ordered, this may be included in delivery or pre-mounted) 5x hex wrench Not shown: Sizes 1.5; 2; 2.5; 3; 7 Warranty card, Clearaudio quality card, return delivery note Screwdriver Not shown: User manual Made in Germany...
-
Page 10: Set-Up
Master Jubilee Pic. 3: Required set-up space IMPORTANT NOTICE: Please double check the tightness of all bolts, hardware and mounting pods, as temperature fluctuations during transit may have caused the hardware to become loose. Page 10 © clearaudio electronic GmbH, 2024-04... - Page 11 Place these flat pads on your hifi-rack or another suitable base, to the final position of your Jubilee turntable. 3.2) Remove the entire upper packaging level from the box. Master Jubilee Take out the turntable body and place its pre-assembled feet (spikes) on the previously positioned flat pads. Pic. 4:...
- Page 12 Art. No. AC068). Pic. 8: Oiling the bearing shaft 3.6) Remove the protecitve film from the sensor mounted in the turntable chassis. Please remove the protective film carefully to avoid any soiling and scratches. Page 12 © clearaudio electronic GmbH, 2024-04...
- Page 13 User manual 3.7.) Using both hands, carefully take the stainless steel sub-platter out of the box. Remove the protective film from the sensor ring on the underside of the sub-platter. Again, please remove the protective film carefully to avoid any soiling or scratches. Carefully slide the upper part of the bearing through the opening of the sub-platter and fix the upper part of the bearing using the mounting clip supplied.
- Page 14 Please ensure that the platter is at least room temperature (approx. 20°C) while mounting to avoid any damage to the bearing. Avoid major side forces to avoid any damages to the ceramic bearing! Pic. 12: Mounting the POM platter Page 14 © clearaudio electronic GmbH, 2024-04...
- Page 15 User manual 3.11) To finally align the motor unit, use the provided template. Pic. 13: Template for aligning the motor unit Place the adjustment template on the left base as shown in Picture 14. The adjustment template has a small tip that fits into the belt recess on the motor unit. Move the motor unit carefully until the template fits perfectly against the turntable.
- Page 16 To ensure that the belt does not come off when the turntable is started for the first time, we recommend holding the flat belt in position with your finger and turning the platter by hand until the belt remains in the correct position. Pic. 16: Mounting the belt Page 16 © clearaudio electronic GmbH, 2024-04...
- Page 17 User manual Close the motor unit with the supplied motor cover. Make sure that magnets are on top of each other. Pic. 17: Placing the motor cover 3.14) Please connect the mains plug to your power supply. Pic. 18: Connection power supply and motor Made in Germany Page 17...
-
Page 18: Mounting Of Tonearm And Cartridge
4.3) For mounting and adjustment of the cartridge, please proceed as described in the relevant cartridge user manual. Clearaudio offers a selection of professional setting tools for your turntable. Please contact your dealer / distributor for more information. Page 18... -
Page 19: Initial Operation And Calibration Of The Speed
To start operating the turntable at the desired speed, press the relevant labeled button on the motor housing. We recommend letting the turntable run for about 15-30 minutes when using it for the first time. Pic. 20: Control panel ´Master Jubilee 5.2) Reference Jubilee Thanks to the newly developed motor control, the turntable calibrates itself automatically in order to always maintain the perfect speed. - Page 20 The respective key assignment can be found in the table below. Speed 33 1/3rpm 45rpm 78rpm 45rpm 33 1/3rpm 78rpm 78rpm 33 1/3rpm 45rpm If you want to reset this setting, proceed as described in point 5.2. Page 20 © clearaudio electronic GmbH, 2024-04...
-
Page 21: Troubleshooting
Is the stylus damaged? Check the stylus and have the cartridge checked by a specialist if necessary. Clean the record / or the cartridge. Clearaudio Is the record or the stylus dirty or damaged? offers many helpful accessories for care and cleaning. - Page 22 User manual Is the record or the stylus dirty Clean the record / or the cartridge. Clearaudio or damaged? offers many helpful accessories for care and cleaning. In the event of damage, we recommend Needle bounces an assessment by a specialist and, if necessary, or slides across an exchange.
-
Page 23: Technical Data
(with tonearm base, without tonearm) Manufacturer warranty: 5 years* * Provided that the warranty card is correctly completed and returned to Clearaudio, or your product is registered online at https://clearaudio.de/en/service/registration.php, within 14 days of purchase. Made in Germany Page 23... -
Page 24: Warranty Information
Le reçu ou la facture constituent des preuves suffisantes. DEUTSCH GARANTIE Bei Garantiefragen wenden Sie sich bitte zunächst an Ihren Clearaudio Händler. Heben Sie Ihren Kaufbeleg gut auf. WICHTIG! Die Angaben auf Ihrer Quittung erlauben uns die Identifizierung Ihres Gerätes und belegen mit dem Kaufdatum die Dauer Ihrer Garantie-Ansprüche. - Page 25 ESPAÑOL GARANTIA Para obtener información acerca de la garantia póngase en contacto con su distribuidor Clearaudio. GUARDE SU RECIBO DE COMPRA Su recibo de compra es su prueba permanente de haber adquirido un aparato de valor, Este recibo deberá guardarlo en un lugar seguro y utilizarlo como referencia cuando tenga que hacer uso del seguro o se ponga en contacto con Clearaudio.
-
Page 26: Stroboscope Testrecord User Manual
33.3 Hz, 45 Hz and 78 Hz (starting from the outer diameter). Stroboscope Testrecord Please place the on your turntable platter and start the engine of your turntable. The big advantage of the Clearaudio Stroboscope Testrecord is, that you can place your cartridge onto the Stroboscope Testrecord , while measuring the speed, as there are grooves provided on the disc. - Page 27 With the outside scale you can detect the speed of 33 Hz and with the inside scale you can detect Stroboscope Testrecord the speed of 45 Hz. Again, the big advantage of the Clearaudio is, that you can place your cartridge onto the strobe record, while measuring the speed, as there are grooves provided on the disc.
- Page 28 Handmade in Germany Clearaudio Electronic accepts no liability for any misprints. Technical specifications are subject to change or improvement without prior notice. Product availability is as long as stock lasts. Copies and reprints of this document, including extracts, require written consent from Clearaudio Electronic GmbH, Germany.
