4.5 Communication Interface Description
Pin number
Note: The RS232 interface can be connected to the eSolar
GPRS/4G/WiFi module. For operation details, please refer to the
quick installation guide of each monitoring module.
Fig. 4.10 RS232 pins
2
3
4
Table 4.3 RS232 pins description
Name
RS-232 TX
RS-232 RX
GND
- 44 -
