Ground Connection; As1 Device Wiring Terminals - SAJ AS1-3KS-5.1 User Manual

Hide thumbs Also See for AS1-3KS-5.1:

Table of Contents

GRID

BACKUP

Fig.4.4 AS1 device wiring terminals

Step 5: Ground Connection

Remove the external hex head screw and lead a grounding line

through OT terminal, screw it into the grounding port of AS1enclosure

(in clockwise direction ) and make sure it is screwed up tightly.

- 37 -
