2.2 System Schematic

The schematic of PV system is shown below:

2.3 Product Model Description

AS1 – XKS – XX
② ③ ④
①
AS1 represents the product series.
①
XK indicates the rated power of the product XkW, such as 3K
②
for 3kW.
S represents single phase; T represents three phase.
③
Fig. 2.1 System schematic diagram
- 14 -
