7 . 2 T h e O u t p u t 1 S t a t e ( F L T )
At default the FLT output is programmed as negative applied. The following states can be
chosen for this output:
State Output Type
1 Negative Applied
2 Negative Removed
3 Positive Applied
4 Positive Removed
5 Negative Logic
6 Positive Logic

7.2.1 Output 1 State 1 Negative Applied:

Dial
A 'BEEP' will be heard
Dial
"SAVED, PLEASE ENTER COMMAND" will be
heard
Dial
a 'BEEP' will be heard
Dial
"SAVED, PLEASE ENTER COMMAND" will be
heard. You will be returned to the engineer menu.

7.2.2 Output 1 State 2 Negative Removed:

Dial
A 'BEEP' will be heard
Dial
"SAVED, PLEASE ENTER COMMAND" will be
heard
Dial
a 'BEEP' will be heard
Dial
"SAVED, PLEASE ENTER COMMAND" will be
heard. You will be returned to the engineer menu.
RINS119-5
for Negative applied for Output 1
for Negative removed for Output 1
VOCALISER INSTALLATION MANUAL
"OFF State"
No Voltage
0V
No Voltage
12V
12V
0V
"ON State"
0V
No Voltage
12V
No Voltage
0V
12V
Page: 15
