1 . 3 T h e V o c a l i s e r U n i t
The Vocaliser fits into the Vocaliser casing as shown below. There is also space in the casing
for a back up battery (7.2V).
Space for a back-
up battery (7.2V)
1 . 4 T e c h n i c a l S p e c i f i c a t i o n
Electrical
Supply Voltage
Current Consumption
Positive Trigger Voltage
Negative Trigger Voltage
Input Response Time
Telephone Line (A, B)
Series Connection (A1, B1)
Battery
Dimensions
PCB Dimensions
Casing Dimensions
Material
Colour
Weight
Environmental
Operating Temperature
Storage Temperature
Vocaliser Microphone (Orbiter)
Frequency Response
Impedance
Power Supply
Sound Pressure Level
Sensitivity
Dimensions
RINS119-5
The Vocaliser is Environmental Class 2.
VOCALISER INSTALLATION MANUAL
Screw that connects the lid
9V – 16V DC
70 mA normal – 270 mA max
4.5V
1.5V
330 ms
DTMF tone dialling
Available only on relay version
7.2V
85 x 145 x 15mm
104 x 185 x 36mm
UL 94 – V0 ABS
White
280g
0ºC to 40ºC
-20ºC to 60ºC
50Hz to 8KHz
1K OHM +/- 30%
1.9V TO 9V
120dB Max
-62dB +/- -3dB
9.8mm Diameter, 7.0mm Thick
Vocaliser PCB
