TAG RCK-PWR Assembly Instructions Manual

Tag 6'x8' half rack

Advertisement

Quick Links

MODEL # TAG 6'x8' Half Rack
ASSEMBLY INSTRUCTIONS
www.tagfitness.net
630-375-1500

Advertisement

loading
Need help?

Need help?

Do you have a question about the RCK-PWR and is the answer not in the manual?

Questions and answers

Summary of Contents for TAG RCK-PWR

  • Page 1 MODEL # TAG 6'x8' Half Rack ASSEMBLY INSTRUCTIONS www.tagfitness.net 630-375-1500...
  • Page 2: Parts List

    PARTS LIST Description Q’ty Description Q’ty Front Upright Frame Plastic Cover 360*70*5 Rear Upright Frame Plastic Cover 70*70*5 Base Fame Plastic Cover 160*70*5 Rear Cross Frame Plastic Cover 205*76*5 Cross Frame Plastic Cover 85*76*5 Upper Cross Frame Plastic Cover 76*70*5 Front Cross Frame Rubber Foot J-Hook (Left)
  • Page 3: Exploded Drawing

    Exploded Drawing...
  • Page 4 Assembly Step 1 Assemble Base Fame (3) and Rear Cross Frame (4), fixing with outer fixing plate (14) and Inner fixing plate(15) using Flat Washer Φ20*Φ34*3(25), Spring Washer Φ18(26),Nut M18(27) and Hex Bolt M18*120(29). Please don’t tighten all bolts in this step.
  • Page 5 Step 2 Assemble Upright Frame (1&2) on the finished assembly from step 1, using Flat Washer Φ20*Φ34*3 ( 25 ) , Spring Washer Φ18(26), Nut M18(27) and Hex Bolt M18*120(29). Please note the ‘ARROW’ in the end of rear upright should face front or rear. The side with number in front upright should always face front.
  • Page 6 Step 3 Assemble Cross Frame(5) and Upright Frame (1&2) using Flat Washer Φ20*Φ34*3(25), Spring Washer Φ18(26),Nut M18(27) and Hex Bolt M18*110(28). Please tighten all the bolts in the above steps.
  • Page 7 Step 4 Install Upper Cross Frame (6) and Front Cross Frame (7) to Upright Frame (1&2) using Flat Washer Φ20*Φ34*3(25), Spring Washer Φ18(26),Nut M18(27) and Hex Bolt M18*110(28). Please tighten all the bolts. Step 5 Install Plate Storage Holder (12) to Back Upright Frame (2) using Lock Nut Φ40*M12*41(13);...
