Page 1: Assembly Instructions
MODEL # RCK-CDR22 ASSEMBLY INSTRUCTIONS same instructions for CDR22S & CDR22L www.tagfitness.net 630-375-1500... -
Page 2: Parts List
PARTS LIST Description Q’ty Description Q’ty Upright Frame Flat Washer Φ9*Φ16*1.6 Cross Frame 2234*228*37*4 Flat Washer Φ13.5*Φ24*2.5 Saddles 166*46.5*67 Spring WasherΦ8 Saddles 158*47.5*40 Nut M8 Rubber Foot 169*129*16 Nut M12 Hex Bolt M8*15 Name Plate Hex Bolt M12*30 Rivet Φ4*12 Hex Bolt M8*15 Exploded Drawing... - Page 3 Assembly Step 1 Install Cross Frame 2234*228*37*4(2) to Upright Frame (1) using Hex Bolt M12*30(7), Flat Washer Φ13.5*Φ24*2.5(10) and Nut M12 (13). Step 2 Install Cross Frame 2234*228*37*4(2) to Upright Frame (1) using Hex Bolt M12*30(7), Flat Washer Φ13.5*Φ24*2.5(10) and Nut M12 (13).
