- Page 1 MODEL # RCK-KBR3 TAG 3 TIER KETTLEBELL RACK ASSEMBLY INSTRUCTIONS www.tagfitness.net 630-375-1500...
- Page 2 Exploded Drawing & Part List PARTS LIST PART NO PART NAME QUANTITY Support Frame Upper Shelf Middle Shelf Lower Shelf Rubber Foot Name Plate Flat Washer Ф11*Φ20*2 Lock Nut M10 Bolt M10*20 Rivet...
- Page 3 Assemble Step Assemble Support Frame(1) and Shelf(2&3&4) using Flat Washer Ф11*Φ20*2(7), Lock Nut M10(8) and Bolt M10*20（9）. Please tighten all the bolts and nuts.
