Instrument Overview
Front and Side View
1
Item
1
Touch Screen Display
2
Door Handle
3
Internal Printer (optional)
4
Cooling Fan
5
Communication Access
6
Fuses
7
Power Switch
3
2
Description
Shows menus, method parameters, etc. Includes 86 dB speakers
Permits ease of opening instrument door
Permits printing of method parameters, graphs and/or method data
Draws room air past the electronics
Permits access to USB, Ethernet, and RS232 ports
Prevent electrical power overload
Turns AC power on and off to the instrument
Instrument Overview
5
6
4
7
5
