Cavity
Fluoropolymer-coated microwave cavity.
5
Item
1
Door Seal
2
Waveguide Covers
3
Turntable Drive Lug
4
Floor Mat
5
Door Inerlock
*
Temperature Sensors
*
Turntable Sensor
*
Vessel Counting Sensor
*Not visible in photo: Temperature sensors, turntable sensor & vessel counting sensor
1
Description
Ensures tight fit between door and interior cavity of the MARS 6 to prevent microwave
leakage
Evenly distribute microwaves into instrument cavity
Allows the turntable drive shaft to pass through the cavity floor and engage the
Turntable
Protects the Teflon Coating on the Floor of the Mars 6 Cavity
3 door safety interlocks and an interlock monitoring system to prevent microwave emission
when the door is open
Measures temperature
Detects type of turntable
Counts number of vessels in the turntable
Instrument Overview
2
2
3
4
7
