Back and Side View
4
2
1
Item
1
Power Cord Receptacle
2
Cavity Exhaust Outlet
3
Cavity Exhaust Blower
4
External Sensor Port
5
Cooling Fan
6
Nameplate
6
3
Description
Receives the female end of the power cord
Exhausts fumes from the microwave cavity
Directs air from the microwave cavity to the exhaust outlet at the rate of 3.6 m
ft
/minute)
3
Permits interface of optional instrument features
Draws room air past the electronics
Lists model, serial number, operating voltage, frequency, and current draw
6
5
Instrument Overview
3
/minute (125
