3.4
LCD Display Module
The system includes a front panel module that serves as an interface
to the internal system components and relays external messages
through the LCD display screen.
Refer to section 2.1.3 for more
information.
The figure below shows the LCD display module connections with the
system board.
CN1
CN16
3-22
AcerAltos 21000 System Guide
