Item
17
Hot-swap redundant
Fan cage
18
Expansion slots
19
SCSI knock-out port
2.1.3

LCD Display Module

The LCD display is an 8-line by 16-character screen that indicates the
boot status as well as any BIOS checkpoint errors encountered upon
system initialization.
controller firmware send the LCD display messages that appear on
the screen. However, if you hooked up a special purpose driver to
control the LCD module, this driver defines the messages. See the
driver manual for more information. For a lists of LCD messages
from the system BIOS, please refer to Appendix A.
Main Menu
> H/W Monitor
Event Log
Reset System
Help
<Menu> - Select
<Enter> - Execute
The main menu consists of four submenus.
submenus, press the Select button (left button) to choose and then
press the Enter button (right button) to activate the submenu.
2-6
Allows the system fan to be removed
and installed even when the system is
operating. See section 2.6.
Expansion cards installation. See
section 2.7.
Allows installation of an external SCSI
port.
Normally, the system BIOS and the micro-
AcerAltos 21000 System Guide
Description
To access these
