Cable Connections

The power backplane is complete with connectors to accommodate
the power cables for all the system components.
labeled with a cable number, and each cable's point (head and tail) is
also numbered, because each cable can only fit one way and is not
interchangeable.
connectors, please refer to the power cable list in this section.
The figure below illustrates the power cables that connect to the
system board and the SCSI backplane board.
SCSI Backplane
Board
CN# - System board connectors
C# - Cable number
P# - Cable point (head and tail)
System Housing
For a list of all the cables and their respective
C4:P
C4:P
CN9
System Board
Power Backplane Board
C1:P
C2:P
C3:P
Each cable is
C1:P2
CN15
C2:P2
CN15
C3:P2
CN22
2-37
